Mocka Addi Tallboy Assembly Instructions Manual page 6

Addi Tallboy
Assembly Instructions
9
3
Slide panel [11] between the grooves of panels [3] and [4] to form the
back of the unit, as shown.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
4
11
10
×
Q
Q
S
L
12
S
L
12
Attach the legs [12] to panel [2] with 4x big dowels (S) and 4x nuts (L)
as shown. Secure with 4x long Allen bolts (Q). Tighten with an Allen
key (M).
Q
Q
2
S
12
L
M
Q
S
L
6
