Mocka Addi Tallboy Assembly Instructions Manual page 10

Addi Tallboy
Assembly Instructions
17
Drawers x4
15
20
P
A
19
x4
Insert 5x small bolts (O) into panels [19]. Secure panels
[15], [16] and [20] to panels [19] with 1x dowel (A) and
5x small locking nuts (P). Tighten with a screwdriver. Slide
panel [21] down along the grooves between panels [15] and
[16] to form the base of the drawer.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
O
O
O
P
19
x4
16
P
21
15
19
x4
18
Drawers x4
O
O
16
Attach panel [22] to panels [15], [16] and [20] using 6x screws (R). Now
attach 1x slide rail (I) to panel [13] and 1x slide rail (H) to panel [12] as
shown. Secure with 4x small screws (E) and tighten with a screwdriver.
R
15
22
E
16
E
19
x4
I
19
x4
R
R
16
E
E
H
15
10
