Aesculap ® AdTec ® mini Assembly / Disassembly Instructions
DISASSEMBLY
1. Deactivate ratchet on ratchet 2. Disconnect shaft and handle
handle Pull rotation knob back and let movable part of the
handle move downwards.
Flip down red toggle switch.
N.B.: for PO381R only
ASSEMBLY
Notch Labelling
1. Assemble shaft 2. Assemble shaft
Slide the push rod into the jaw insert as far as it Rotate the push rod 90° clockwise until it locks into
will go making sure that the labelling on the push place. The groove is then in line with the notch.
rod is in line with the notch of the jaw part.
MAINTENANCE
Lubricate the parts of the instrument specified (jaws and red toggle
switch) with Aesculap Sterilit Oil after each cleaning cycle.
3. Remove shaft from handle
Remove the shaft by pulling the instrument shaft
out of the handle.
Notch Groove
3. Assemble shaft
Slide the black outer tube as far as it will go over
the jaw insert.
4. Disassemble shaft
Hold the jaw insert at the tip and remove the outer
tube.
4. Prepare handle
Deacitvate the ratchet by flipping down the red
toggle switch.
N.B.: for PO381R only
Jaw insert
Push rod
Outer tube
Toggle switch
Rotation knob
Movable part of handle
Aesculap Endoscopic Technology
Notch Labelling
5. Disassemble shaft 6. Disassemble shaft
Rotate the push rod 90° counterclockwise until the Remove the push rod.
labelling is in line with the notch of the jaw part.
5. Connect shaft and handle 6. Function test
Hold the tip of the shaft and the rotation knob of the Test the assembly of the instrument by opening and
handle firmly. Slide the shaft into the handle until closing the handle to ensure the jaw is openinig and
it locks into place, making sure that the push rod closing.
notch is in line with the mark on the rotating knob.
Important: Do not touch the movable part of the handle.
REPROCESSING & ACCESSORIES REPAIRS
In order to ensure the preservation of full guarantee
Reprocess the product immediately after use
and warranty rights, only persons authorized by
The product can be sterilized either in
Aesculap may carry out repairs.
disassembled or in assembled condition
Please send products for repair to:
For advice on cleaning, disinfection and sterili- Aesculap Technical Service, Am Aesculap-Platz,
78532 Tuttlingen, Germany.
zation, please follow the instructions for use
Additional service addresses may be obtained from
For the latest information on reprocessing,
the same address or via ats@aesculap.de
please also refer to the Aesculap Extranet via
www.aesculap-extra.net
For accessories and spare parts, please refer
to brochure C28011 and C28511 or visit
www.endoscopy-catalog.com
