Installing The Router In The Rack - Avaya IG550 Installing And Configuring

Note:
The TIMs and Physical Interface Modules PIMs should already be installed in the
Note:
router chassis. If you have modules that are not already inserted, insert the
modules as shown in
if necessary
3. Label the DB-9 adapter and the flat rollover cable for the TGM550 to say "TGM550". Label
the DB-9 adapter and Ethernet cable for the router console to say "router."
4. Verify that the equipment matches the packing list.
5. Verify that the equipment matches the list of equipment from the project manager.

Installing the router in the rack

1. If the customer has a four-post rack and is using a shelf, install the shelf according to
manufacturer guidelines. Set the router on the shelf.
2. If the customer is using the brackets supplied with the router, do the following:
a. Partially screw customer-provided bolts or screws in to a 19-inch (48 centimeters) rack.
Note:
These bolts or screws are for the resting holes.
Note:
b. Temporarily slide the resting holes of the brackets over the resting bolts or screws.
Ensure that a mounting screw position exists for the two top holes and two bottom holes.
c. Install the mounting brackets onto the chassis, as needed. Avaya recommends that you
use the center-mount chassis holes in the center of the chassis sides to mount the
brackets.
Inserting the TGM550, the TIMs, and the PIMs in the router,
on page 43.
Issue 1.1 May 2007 15
