Quick Start for Hardware Installation: IG550 Integrated
Gateway
Preparing before you go on-site
1. Check Juniper software compatibility with TGM550 Gateway Module firmware. See
support.avaya.com.
2. Download the most recent firmware for the TM550. See http://support.avaya.com.
3. Ensure the customer has an FTP or TFTP server that is accessible to the TGM550. If not,
download a TFTP server to your laptop.
4. Review safety requirements and airflow requirements. See Installing and Configuring the IG550
Integrated Gateway.
5. Get the tools you need:
Electrostatic discharge (ESD) grounding strap
●
Flathead and Phillips head screwdrivers
●
Getting ready on-site
1. Verify you have:
The Juniper Services Router (J4350 or J6350).
●
A 10 AWG grounding cable
●
An AC or 14 AWG DC power cable
●
Cables for the TGM550, Telephony Interface Modules (TIMs), and Physical Interface Modules
●
(PIMs).
!
CAUTION:
You cannot use a 14 AWG grounding cable with the router. The grounding cable must be
CAUTION:
10 AWG.
A USB modem
●
Two distinct and different console cables:
●
- An RJ-45 console cable and DB-9 adapter for console connections to the TGM550.
- An RJ-45 rollover cable and DB-9 adapter for console connections to the Juniper router.
03-601553 Issue 1 February 2007
700431984
03-601553
Issue 1
February 2007
http://
1
