Summary of Contents for Squareled EXPO
-
Page 2: Product Overview
Manual | EXPO 1. Product Overview... -
Page 3: Mechanical Specification
Manual | EXPO 2. Mechanical Specification Packaging: Thanks for your purchasing the AH055. All the lights have been checked and are in excellent operating condition. Please check the shipping carton first,because there may be damage occurred during the shipment.Then check the lights carefully and be sure that the lights is intact and works normally.In the event damage has been found, spare parts are missing or the lights works abnormally,please contact us for further instructions. - Page 4 Manual | EXPO 4. Features • Light Source:31*10W CW LEDs • Lens:20° • Power consumption:350W • Voltage:100V-240V, 50/60Hz • Run Mode: DMX 512/Master Slave/Auto Run • 4 different dimming curve • Maximum 66 ID setng for easy separate control • DMX Channels: 1, 2 & 5CH •...
-
Page 5: Programme Menu
Manual | EXPO 5. Programme Menu... - Page 6 Manual | EXPO 7. Displayer introduction 1. DMX means the light is in the DMX mode.Similarly,SLAVE means the light is in the SLAVE mode. 2. The color of the point shows the condition of signal transmission. Green represents the good condition, while red represents the signal is interrupted.
- Page 7 Manual | EXPO ENTER, and you can see three items as below: 1) Software - This item displays the Software information. 2) Hardware - This item displays the Hardware information. 3) Fix times - This item displays the working hours about the light.
-
Page 8: Dmx Control Mode
Manual | EXPO 8. DMX control mode DMX 1 channel channel value function 0 - 255 Adjust CW All LED dimmer DMX 2 channel channel value function 0 - 255 Adjust CW All LED dimmer 0 - 8 NO function... -
Page 9: Dmx-512 Addressing With Id Address
Manual | EXPO Channel 5 (Id address set) 0 - 9 all Ids 170 - 179 Id17 Id34 Id51 10 - 19 180 - 189 Id18 Id35 Id52 20 - 29 190 - 199 Id19 Id36 Id53 30 - 39... -
Page 10: Cable Connectors
Manual | EXPO 10. CABLE CONNECTORS Cabling must have a male XLR connector on one end and a female XLR connector on the other end. DMX connector configuration Caution: Do not allow contact between the ground and the fixture’s chassis ground. Grounding the ground can cause a ground loop, and your fixture may perform erratically. -
Page 11: Photometric Data
Manual | EXPO 11. Change LED board 1. Remove the nine screws on the light panel with a screwdriver. 2. Take down the whole light panel. 3. And then install the whole light panel of 25 degree. 12. Photometric Data... - Page 12 Manual | EXPO Das Lichttechnikhaus Vertriebs GmbH Rudolf-Diesel-Str. 3, D-89312 Günzburg Telefon +49 (0) 82 21 207 98-0 +49 (0) 82 21 207 98-69 E-Mail info@lth-gmbh.de www.lth-gmbh.de...
