Summary of Contents for Squareled tricolor ip65
-
Page 2: Safety Instruction
Manual | TriColor IP65 14x3W(6in1) 1. Summarization Summarize: Thank you for purchasing our SquareLED TriColor . Please read these instructions careful- ly before begin and operate the fixtures according to these instructions to avoid any possible damages and accidents causes by misusage. -
Page 3: Outside Size Picture
Manual | TriColor IP65 14x3W(6in1) 3. outside Size Picture 4. Main Function » high quality LED:low consumption,brighness, stable capability and long life » each color of LED with 256 dimming. RGB can make over 16.7 million colors » Linear dim 0%-100%, Stobe, gradual change, jumping change »... - Page 4 Manual | TriColor IP65 14x3W(6in1) 7 CH Mode: channel DMX value Control Function Remarks Priority 0-255 General Dimming 0——100% Must use this channel, otherwise no function of dimming 0-255 Red Dimming 0——100% Or Amber color 0-255 Green Dimming 0——100% Or white color 0-255 Blue Dimming 0——100%...
-
Page 5: Display Operation
Manual | TriColor IP65 14x3W(6in1) 6. Display Operation POWER IN POWER OUT DMX IN DMX OUT MENU UP DOWN ENTER » MENU: access the menu or return to a previous menu option » UP: menu selection or parameter increments »... -
Page 6: Menu Instruction
Manual | TriColor IP65 14x3W(6in1) 7. Menu Instruction Addr A001-‐A512 DMX M ode SLAU SL.AU Slave M ode ... - Page 7 Manual | TriColor IP65 14x3W(6in1) 1. Operating instruction: MENU > Enter > UP/DOWN > ENTER MENU is used to access the menu or return to a previous menu option. It can not be used to select and store the current menu option. Press UP / DOWN to choose a desired menu item. Here are the operati- on details : »...
-
Page 8: Operating Control Instruction
Manual | TriColor IP65 14x3W(6in1) 8. Operating Control Instruction Master/Slave: Master: The master should always working as a master as long as it is not set in a DMX mode whate- ver other modes it is. And it send out the signal so that the slave synchronous with it. To avoid the host signal and DMX512 signals interfere with each other, should cut off the DMX512 signals. -
Page 9: Connecting Picture
Manual | TriColor IP65 14x3W(6in1) The Conversion between 3 pin and 5 pin XLR If the output cable of DMX512 controller is the 5PIN, please use 1pc 5PIN to 3PIN cable 10. Connecting picture Light connecting picture: ... -
Page 10: Troubleshooting
Manual | TriColor IP65 14x3W(6in1) 11. Trouble Shooting Problem Checking Way • Check the power source plug is in normal or not • Check the switch of the lights is off or on Can not turn on the light •... -
Page 11: Technical Specification
Manual | TriColor IP65 14x3W(6in1) 12. Technical Specification • Input voltage: AC100V-264V/47-63HZ • Output voltage: DC32V • Consume: 52W • Lamp Type: High Power LED(3W) • Lamp Spec: 3-in-1 LED (14 PCS) • Control Signal: DMX512, Master-Slave • Control mode: stand alone/ DMX/ master and slaver •... - Page 12 Das Lichttechnikhaus Vertriebs GmbH Rudolf-Diesel-Str. 3, D-89312 Günzburg Telefon +49 (0) 82 21 207 98-0 +49 (0) 82 21 207 98-69 E-Mail info@lth-gmbh.de www.lth-gmbh.de...
