- Page 2 SquareLED Zyclone 300W RGBAL User Manual IP65 ①...
-
Page 3: Safety Instructions
SAFETY INSTRUCTIONS CAUTION Be careful with your operations. With a dangerous voltage you can suffer a dangerous electric shock when touching wires! This device has left the factory in perfect condition. In order to maintain this condition and to ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes written in this user manual. - Page 4 Please install and operate the fixture with following instructions. Meanwhile, please keep this manual well for future needs. The SquareLED Zyclone 300W RGBAL is made of a new type of high temperature strength of die cast aluminum casing with nice outlook. The fixture is designed and manufactured strictly following CE&RoHS standards, complying with international standard DMX512 protocol.
-
Page 5: Features And Specifications
FEATURES & SPECIFICATIONS Feature： * 1 * 300W COB LED (RGBAL 5IN1) * 50,000 hours life time and low power consumption * Optimized high definition optical system for improved photometric performance and field uniformity * Projector-quality, high contrast aspheric lens * Glass reflector that removes greater than 90% infrared radiation (heat) and reflects greater than 95% of visible light * Beam Angle: 15°to 30°... -
Page 6: Dmx-512 Control Connections
DMX-512 CONTROL CONNECTIONS Connect the provided XLR cable to the female 3-pin XLR output of your controller and the other side to the male 3-pin XLR input of the moving head. You can chain multiple Moving head together through serial linking. The cable needed should be two core, screened cable with XLR input and output connectors. - Page 7 COMMON 1:Ground DMX+ 2:Data(-) 3:Data(+) DMX- DMX Input 3-Pin XLR DMX512 Out DMX512 In 3-Pin XLR 3-Pin XLR 120Ω Pin3 Pin2 For installations where the DMX cable has to run a long distance or is in an electrically noisy environment, such as in a discotheque, it is recommended to use a DMX terminator. This helps in preventing corruption of the digital control signal by electrical noise.
-
Page 8: Product Feature
Product Feature 2 kinds of running model External control mode (Slave model) DMX 512 controller control(2 kinds channel modes) Master/salve model control (auto match the signal from controller and the Master light, no need to set by menu) ... -
Page 9: Operation Status
Main Menu 6.1 Main Menu Reverse Display Running Status Vice Menu Button 6.2 Operation Status Mode Display Description “A”stand for standard channel mode, “xxx”stand for ID address, Auto identify DMX Mode Axxx Master-slave controller signals or host signals “D”stand for basic channel mode, “xxx”stand for ID address, Auto identify Dxxx controller signals or master signals “M”stand for Master mode，“MC”stand for “Mixed Colort”... -
Page 10: Dmx Settings
DMX Settings Menu Operation Option Description Press key of “OK” enter to DMX Start Address 1~512 edit mode, press “UP” and ”down” to edit the DMX address Press key of “OK” change DMX Profile 22CH Standard Channel Mode the DMX channel mode Basic Channel Mode Master Mode Choice Menu... - Page 11 Settings Menu Operation Option Description Touch Screen Calibration Touch screen adjust White Point Edit Color temperature correction Reset Calibratioin Reset correction 500Hz Dimmer Frequency Change dimmer ..frequency 25000Hz Dimmer Curve Change dimmer Standard curve Incandescent Linear Quick Over Temperature Temperature 80~100 Each 5 for increase or...
-
Page 12: Dmx Channels
DMX CHANNELS Standard channel mode (22CH) Channel Data Function Remark 0~255 Dimmer 0~255 Color 1 0~255 Color 2 0~255 Color 3 0~255 Color 4 0~255 Color 5 No function 10~19 color temperature 1 ..color temperature n Each data color temperature No function 10~19... -
Page 13: Operation & Specifications
Basic channel mode(5CH) Channel Data Function 0~255 Color 1 0~255 Color 2 0~255 Color 3 0~255 Color 4 0~255 Color 5 OPERATION & SPECIFICATIONS ·The PROFILE 300RGBAL is for on-site decoration purpose. · Don't turn on the fixture if it's been through severe temperature difference like after transportation because it might damage the light due to the environment changes. - Page 14 Never stand directly below the device when mounting, removing, or servicing the fixture. From a ceiling, or set on a flat level surface (see illustration below). Be sure this fixture is kept at least 0.5m (1.5 ft) away from any flammable materials (decoration etc.). Please ensure that the led profile spotlight is hung using the appropriate "C"...
-
Page 15: Cleaning And Maintenance
Cleaning and maintenance Now ignoring maintenance and cleaning is very good way of creating problems "down the road" and many companies and installations do just that. However the net result is, no matter what the fixture, premature failure! Changing the oil in a car, most people do on a regular basis. So with the fixtures, regular maintenance it an excellent practice, if you want the fixtures to last. - Page 16 Das Lichttechnikhaus Vertriebs GmbH Rudolf-Diesel-Str. 3, D-89312 Günzburg Telefon +49 (0) 82 21 207 98-0 +49 (0) 82 21 207 98-69 E-Mail info@lth-gmbh.de www.lth-gmbh.de...
