Summary of Contents for Squareled Hi-Precision 300W LED Profiler MK2 fixed

  • Page 2: Technical Parameters

    Manual | Hi-Precision 300W LED Profiler MK2 fixed 1. TECHNICAL PARAMETERS 1.1 Electrical Parameters Input Voltage: 100-240AC 50/60HZ Power Consumption: 320W Control Signal: DMX512 Control Channel: 3 channels DMX input/output interface: XLR 3/5PIN Power port: Aviation head Ethernet interface: Optional Display window: 2.4inch colorfullLCD display...
  • Page 3 Manual | Hi-Precision 300W LED Profiler MK2 fixed 2. Illumination Chart 2.1 5600K Illumination...

  • Page 4: Safety Warning

    Manual | Hi-Precision 300W LED Profiler MK2 fixed 2.1 5600K Illumination 3. Safety Warning Notice: • Professional technical people required to install and maintain this equipment. • This equipment has passed strict inspection before delivery. • Users have to obey the safety and notice guide.

  • Page 5: Important Notice

    Manual | Hi-Precision 300W LED Profiler MK2 fixed Important Notice: • Make sure the power supply within the standard data range • he fixture’s power supply connection line can not connectto any other fixtures. • The fixture’s DMX512 signal line can not connect to any other DMX512 signal line.

  • Page 6: Power Connection

    Manual | Hi-Precision 300W LED Profiler MK2 fixed Horizontal place: Lens cone install as shown in the figure below. 1. Arrow and knob aligned in a straight line Arrow and knob aligned in a straight line 2. Put lens cone to the box and rotate clockwise 3.

  • Page 7: Operation

    Manual | Hi-Precision 300W LED Profiler MK2 fixed 4.3 DMX512 Console Connect • Serial connect the DMX512console and signal cable. • DMX512address code is reusable. • DMX512 address code can be any number between 001 to 512. 5. Operation 5.1 Display Window...
  • Page 8 Manual | Hi-Precision 300W LED Profiler MK2 fixed 5.2 MENU • ENTER: Function to the next level submenu and save or confirmation settedfuction data • UP: Select function sub menu,up cycle adjustment data • DOWN: Choose function submenu,circulate down to adjust the data values •...
  • Page 9 Manual | Hi-Precision 300W LED Profiler MK2 fixed 5.3 Manual Setup-STAT • Press [ENTER] in menu to static setting • Press [UP]/[DOWN] or Rolling hand wheel to choose [DIM], [STROBE] • Press [ENTER] to edit state, Press [UP]/[DOWN] or Rolling hand wheel to set, [DIM] setting data is 0~255, [STROBE] setting data is 0~20Hz •...
  • Page 10 Manual | Hi-Precision 300W LED Profiler MK2 fixed 5.5 Light SET • Press[ENTER] in menu [SETTING] to Light set operation • Press [UP]/[DOWN] to choose setting Manuel • Press[ENTER] in menu [MODE] to [DMX] for signal choose mode • Press[DIMMING] to setting mode for linear 6.
  • Page 11 Manual | Hi-Precision 300W LED Profiler MK2 fixed Das Lichttechnikhaus Vertriebs GmbH Rudolf-Diesel-Str. 3, D-89312 Günzburg Telefon +49 (0) 82 21 207 98-0 +49 (0) 82 21 207 98-69 E-Mail info@lth-gmbh.de www.lth-gmbh.de...
