  • Page 2: User Manual

    SquareLED Edgy Akku + Wireless 4x25W RGBAW 5in1 USER MANUAL...

  • Page 3: Table Of Contents

    Catalogue 1. Summary ........................ 1 2. Safety Instruction ....................2 3. Outside Size Picture ....................3 4. Main Function ......................4 5. DMX Control Function .................... 5 6. Display Operation instruction ................8 7. Instruction for compatible Sweden DMX wireless module ........14 8.

  • Page 4: Summary

    Summary  Summary  Thank you for purchasing our SquareLED EDGY. Please read these instructions carefully before begin and operate the fixtures according to these instructions to avoid any possible damages and accidents causes by misusage  Product introduction casting aluminum housing...

  • Page 5: Safety Instruction

    2. Safety Instruction  Safety Notes ! Enquire the skilled people before any repair; ! Always make sure disconnect from the power source before setting up, serving and moving;. ! Avoid direct eye exposure to the fixture when it is on; ...

  • Page 6: Outside Size Picture

    3. Outside Size Picture...

  • Page 7: Main Function

    4. Main Function  Input voltage: AC 100V-264V/47-63HZ  Power consumption：120W  Lamp Type：25W LED 5-in-1 R、G、B、A、W (4PCS)  Life span: 50000~100000hours  PWM Dimmer：1500HZ(16666 grades)  Control Signal：DMX512  Control mode：stand alone/ Master/Slaver  Ifrared keyboard control  2.4G wireless DMX512 ...

  • Page 8: Dmx Control Function

    5. DMX Control Function  DMX Channels 11CH. 10CH 11CH 16CH Value Function 0-255 Dim all 0-255 0-255 0-255 0-255 0-255 0-255 0-255 0-255 0-255 0-255 0-255 0-255 0-255 CH10 CH10 0-255 CH10 CH11 CH11 0-255 No strobe 6-20 Not synchronous strobe(slow to fast) 21-60 Synchronous strobe(slow to fast) 61-100...
  • Page 9 66-70 AUTO 3 71-75 AUTO 4 76-80 AUTO 5 81-85 AUTO 6 86-90 AUTO 7 91-95 AUTO 8 96-100 AUTO 9 101-105 AUTO 10 106-110 AUTO 11 111-115 AUTO 12 116-120 AUTO 13 121-125 AUTO 14 126-130 AUTO 15 131-135 AUTO 16 136-140 AUTO 17...
  • Page 10 of RGB Light Blue (Red=0, Green=full, Blue =full, channel White=0)(step) Red=0, Green=full, Blue->down, 52-90 White=0(proportional) Green (Red=0, Green=full, Blue =0, White=0)(step) Red->up, Green=full, Blue=0, 92-130 White=0(proportional) Yellow (Red=full, Green=full, Blue=0, White=0)(step) Red=full, Green->down, Blue=0, 132-170 White=0(proportional) Red(Red=full, Green=0, Blue=0, White=0)(step) Red=full, Green=0, Blue->up, 172-210 White=0(proportional)

  • Page 11: Display Operation Instruction

    6. Display Operation instruction  MENU : access the menu or return to a previous menu option  ENTER: select the current menu option  UP: menu selection or parameter increments  DOWN: menu selection or parameters decrease Menu Tree LEVEL 1 LEVEL 2 LEVLE 3...
  • Page 12 BAT(battery output) HIGH/MIDDLE/LOW CAL(Calibration) 0-255 0-255 0-255 0-255 0-255 YES/NO CHMD(Channel 16CH/11CH/10CH/11CH./6CH/5CH mode) LIN(linear)/SQR(square law)/ISQR(inverse square DIM(Dimming law)/SCUR(S-curve)/LIN.(linear mode) smooth)/SQR.(square law smooth)/ISQR.(inverse square law smooth)/SCUR.(S-curve smooth) DISY(Display set) ON(Permanent on) 2 OFF (2 minutes off) SHOW ADDR/BAT LOCK YES/NO CTST(Custom CT01 0-255 color set)

  • Page 13: Dmx Address Setting

    0-255 0-255 SHUT 0-255 AUTO NONE,AT01-AT33 ATSP 0-255(S) TIME 0-255(S) WAIT 0-25.5(S) YES/NO SC25（Scene 25） CHS3（Chase 3） INFO SOFT(Software Vx.x （Information) version) BATTERY 0%-100% POW(Power xxx% reduction) TEM1 xxxC TEM2 xxxC LOAD(Load) ST L（Setting load) YES/NO PR L （Program load) YES/NO SEND(Send) YES/NO...

  • Page 14: Channel Mode Setting

    6.3 DMX signal selection setting 1) Press the【ENTER】button in【SIGN】menu, then enter to the DMX signal selection setting. 2) Press the【UP/DOWN】button to select【2.4G】,【CABLE】 3) Press the【ENTER】button to escape and save. 6.4 Wireless set 1) Press the【ENTER】button in【WIRE】menu, then enter to the wireless set. 2)【RESET】Analog the wireless module,it is the process of off and pressing the button then power 3)【KEY】similar as the external key.
  • Page 15 3) Press the【ENTER】button to escape and save. Illustrations：When setting【LIN.】，【SQR.】，【ISQR.】and 【SCUR.】 in 【DIM】 menu, there will be added a little delay dimming effect for smooth.. Dimming curve: Linear curve: square law curve: Inverse Square law curve: S-curve: 6.9 DISPLAY SETTING 1) Press the【ENTER】button in【DISY】menu, then enter to the display setting. 2) Press the【UP/DOWN】button to select【ON】，【2 MINITES OFF】...
  • Page 16 1)Press the【ENTER】button in【AUTO】menu, then enter to the auto run,self-program run. 2)Press the 【UP/DOWN】 button to select 【 AT01】 … 【AT05】 ， 【AUTO SPEED】 ， 【CHASE01】 … 【CHASE03 】 3)Press the【ENTER】button to start running. 6.14 EDIT SELF-PROGRAM 1) Press the【ENTER】button in【PROG】menu, then enter to the edit self-program. 2) Press the【UP/DOWN】button to select【CHASE01】…【CHASE03】...

  • Page 17: Instruction For Compatible Sweden Dmx Wireless Module

    3) Press the【ENTER】button to escape and save. Illustrations： “ADDR” “CTST” and “PROG” are not reset, the others reset to the underlined value of the word. 【PROG】SELF-PROGRAMMING PARAMETER RESET 6.17 1) Press the【ENTER】button in【PR L】menu, then enter to the【PROG】self-programming parameter reset. 2) Press the【UP/DOWN】button to select【YES】.

  • Page 18: Ifrared Keyboard Operation

    same color, can receive and transmit data. User-defined function is not available. Notice: compatible Sweden DMX mode in this lights has complete data for sending and receiving, but transmit function is not available here. 8. Infrared keyboard operation...

  • Page 19: Operating Control Instruction

    【MENU】, 【UP】, 【DOWN】, 【ENTER】is same as the keys on the fixture. 【R1】...【W2】，【SHUT】is shortcut for 【STAT】. 【AT01】,【CHS01】, 【ATSP】,【SOU1】is correspond to the positon of 【AT01】,【CHS01】,【SOU1 】 in the MENU. 【CLEAR】is clear the value of 【R1】, 【G1】... 【SHUT】 then save and reset。 9. Operating Control Instruction ...

  • Page 20: Trouble Shooting

    Note：In order to avoid failures and interference signal transmission，we connect a Resistance 120Ω（1/4W）at the end of the DMX connecting as below:  The Conversion between 3 pin and 5 pin XLR If the output cable of DMX512 controller is the 5PIN, please use 1pc 5PIN to 3PIN cable 11.
  • Page 21  Please check whether the DMX line is near to the high voltage wire or not. In that case, it will damage or interfere the DMX electric circuit.  Check whether the 【CAL】is started or not and the set value is The beam appears too small.
  • Page 22 Das Lichttechnikhaus Vertriebs GmbH Rudolf-Diesel-Str. 3, D-89312 Günzburg Telefon +49 (0) 82 21 207 98-0 +49 (0) 82 21 207 98-69 E-Mail info@lth-gmbh.de www.lth-gmbh.de...
