Summary of Contents for Squareled SPIRIT
-
Page 2: Mechanical Specification
Manual | SPIRIT 1.Mechanical Specification... - Page 3 2. Introduction Unpacking: Thank you for purchasing the SPIRIT Battery Bar. Every SPIRIT Battery Bar has been thoroughly tested and has been shipped in perfect operating condition.Carefully check the shipping carton for damage that may have occurred during shipping. If the carton appears to be damaged, carefully inspect your fixture for any damage and be sure all accessories necessary to operate the unit has arrived intact.
-
Page 4: Safety Information
Manual | SPIRIT 3. Safety Information Installation Make sure all parts for fixing the projector are in a good state of repair. Make sure the point of anchorage is stable before positioning the projector. The safety chain must be properly hooked onto the fitting and secured to the framework, so that,if the primary support system fails, the fitting falls as little as possible. -
Page 5: Product Overview
Manual | SPIRIT The products referred to in this manual conform to the European Community Directives to which they are subject: • Low Voltage Directive 2006/95/EC • Electromagnetic Compatibility Directive 2004/108/EC 4. Product Overview... - Page 6 Manual | SPIRIT 5. Technic 5. Technical Data • Source: 8x 8W LED RGBW 4 in 1 • Led power: 64W • Optics: Secondary optic lens,with 25 degree Head adjustmen: 0-90° • Cooling: Natural cooling by body • Control: Wireless DMX,Master, Slave and sound,auto mode Wirless module: WDMX from sweden •...
- Page 7 Manual | SPIRIT 6. Operating Instructions...
- Page 8 Manual | SPIRIT...
- Page 9 Manual | SPIRIT PROGRAM 1. P: Internal program mode select 1 - 20 2. AUTO : 20 mode loop run 3. S: Adjust internal program speed 0- 31 CUSTOM 1. Run customized program 12 DMXSETUP 1. CH: Setup DMX Channel(3/4/5/8/11/43) 2.
- Page 10 Manual | SPIRIT SETUPDIS 1. OFF: Close lcd backlight. On: Open lcd backlight. RUN MODE 1. Run SLAVE/DMX KEY LOCK 1. 10s :Key lock 10s after open 2. 30s: Key lock 30s after open 3. OFF: Key lock close.Password is UP/DOWN MASTER 1.
-
Page 11: Dmx Control Mode
Manual | SPIRIT 7. DMX control mode Mode 1: 3CH DMX Channel Value Function 0 -255 0 -255 Staturation 0 -255 Value(brightness) Mode 2: 4CH DMX Channel Value Function 0 -255 Adjust red LEDs Dimmer low to high 0 -255... - Page 12 Manual | SPIRIT 28 - 31 blue 32 - 35 yellow 36 - 39 cyan 40 - 43 magenta 44 - 47 white 48 - 51 orange 52 - 55 pink 56 - 59 violet 60 - 63 aquamarine 64 - 67 sky blue...
- Page 13 Manual | SPIRIT 160 - 163 surprise pink 164 - 167 scarlet 168 - 171 surprise peach 172 - 175 fire 176 - 179 english rose 180 - 183 mauve 184 - 187 bright blue 188 - 191 alice blue...
- Page 14 Manual | SPIRIT 61 - 70 R100%G0%Bdown/W0% 71 - 80 R100%/G0%/B0%/Wup 81 - 90 R100%/G0%/B0%Wdown 91 - 100 R↑/G↓/B0%/W0%→R↓G↑/B0%/W0% 101 - 110 R↑/G0%/B↓/W0%→R↓/G0%B↑/W0% 111 - 120 R0%/G↑/B↓/W0%→R0%/G↓/B↑/W0% 121 - 130 R↑/G↑/B↓/W0%→R↓/G↓/B↑/W0% 131 - 140 R↑/G↓/B↓/W0%→R↓/G↑/B↑/W0% 141 - 150 R↑/G↓/B↑/W0%→R↓/G↑/B↓/W0% 151 - 160 R↑/G0%/B↓/W0%→R↓/G↑/B0%/W0%→R0%/G↓/B↑/W0%...
- Page 15 Manual | SPIRIT 21 - 30 program 3 31 - 40 program 4 41 - 50 program 5 51 - 60 program 6 61 - 70 program 7 71 - 80 program 8 81 - 90 program 9 91 - 100...
- Page 16 Manual | SPIRIT Mode 5: 43CH DMX Channel Value Function 0 -255 0 = Off 1 - 255 = Master dimmer 0 -255 Adjust red LEDs Dimmer low to high 0 -255 Adjust green LEDs Dimmer low to high 0 -255...
- Page 17 Manual | SPIRIT 206 - 210 White 2 211 - 215 White 3 216 - 220 White 4 221 - 225 White 5 226 - 230 White 6 231 - 235 White 7 236 - 240 White 8 241 - 245...
- Page 18 Manual | SPIRIT 0 - 255 0 - 8= Default 9 - 255= strobe 0 - 10 Default 11 - 63 Led unique control 64 - 95 Module control 1 96 - 127 Module control 2 128 - 159 Module control 3...
-
Page 19: Dmx Connection
Manual | SPIRIT 8. Connection 8.1 DMX connection Connect all lights with controller,set all chanels are same. 8.2 Master slave connection 8.3 Wireless connection... -
Page 20: Installation
Manual | SPIRIT 8.4 Release wireless DMX signal Relaese signal of wireless DMX. Because there is memory function in the light,the signal of sender or receiver are different,so should be cleaned old signal if use a new sender or receiver. -
Page 21: How To Charge The Battery
Manual | SPIRIT 10. Flight case charge battery Open flight case,connect the inside power cable of flight case with light,and then connect the outside power cable of flight case with socket. 11. How to charge the battery 1. The battery life indicator located on the product displays the remaining amount of internal battery life. -
Page 22: How To Replace The Battery
Manual | SPIRIT 2. Light can be charged when using. 12. Service 12.1. Battery Manual 1. The energy of battery must be finished 100% when charge battery. 2. Should be charge one time each 3 month if do not use light.Must keep a few energy in battery,otherwise the volume of battery will be cut down 20%. - Page 23 Manual | SPIRIT Das Lichttechnikhaus Vertriebs GmbH Rudolf-Diesel-Str. 3, D-89312 Günzburg Telefon +49 (0) 82 21 207 98-0 +49 (0) 82 21 207 98-69 E-Mail info@lth-gmbh.de www.lth-gmbh.de...
