Summary of Contents for Squareled LED MATRIX 16X30W COB BLINDER

  • Page 2: Dimmer

    Manual | SquareLED LED MATRIX 16X30W COB BLINDER 1. Introduction When you get this product, please take it from carton carefully to make sure whether all the accessories are in and damaged or not. When you find that there are any parts or wrong sign with the carton, or non-operation, please inform us and to keep the carton and shipping bill completely.
  • Page 3 Manual | SquareLED LED MATRIX 16X30W COB BLINDER 3. Features » 96/48/24/6 DMX channels. » RGB 3-in-1 COB LED light source » life long is 50000-10000 hours. » Variable electronic dimmer(0-100%). » Control mode: Auto,sound, DMX512 mode » Cool: temperature protector 4.
  • Page 4 Manual | SquareLED LED MATRIX 16X30W COB BLINDER Red (13, 14, 15, 16) Red (8) Green (13, 14, 15, 16) Green (8) Blue (13, 14, 15, 16) Blue (8) Red (1, 5, 9, 13) Red (9) Green (1, 5, 9, 13)
  • Page 5 Manual | SquareLED LED MATRIX 16X30W COB BLINDER Red (4) Green (4) Blue (4) Red (5) Green (5) Blue (5) Red (6) Green (6) Blue (6) Red (7) Green (7) Blue (7) Red (8) Green (8) Blue (8) Red (9)
  • Page 6 Manual | SquareLED LED MATRIX 16X30W COB BLINDER Red (16) Green (16) Blue (16) DMX Channel (24/6CH) Channel 24CH Red (1, 2, 3, 4) Red (1) Green (1, 2, 3, 4) Green (1) Blue (1, 2, 3, 4) Blue (1)

  • Page 7: Fixture Linking

    Manual | SquareLED LED MATRIX 16X30W COB BLINDER 5. Setup Fixture linking When you control the light‘s master/slave or DMX 512 signal agreement, the lights can be connected by signal wire which the distance is = 500 m,The maximum connect lights are 32pcs more or less, and adapt DMX light pair to segregate the signal zoom equipment, in order to protect the light’s signal won’t be interrupted by...

  • Page 8: Operating Instructions

    Manual | SquareLED LED MATRIX 16X30W COB BLINDER 6. Operating instructions Menu configure There are 4 buttons located in the bottom of the LED digital display when you check the menu configure of the bottom of light. Show as follow:...
  • Page 9 Manual | SquareLED LED MATRIX 16X30W COB BLINDER Menu function map DMX512 Control Address Control Red Dimmer Value: 000-010 Dimmer Control Green Dimmer Value: 000-010 Blue Dimmer Value: 000-010 Strobe Speed: 001-010 Red Dimmer Value: 000-010 Menu Strobe Control Green Dimmer Value: 000-010...

  • Page 10: Mix Color

    Manual | SquareLED LED MATRIX 16X30W COB BLINDER To set DMX mode The light can connect to the DMX controller to receive its signal indication, which control by DMX controller. DMX value is referenced by „DMX Channel Values“ DMX channel values...

  • Page 11: Red + Green Color Fade

    Manual | SquareLED LED MATRIX 16X30W COB BLINDER Blue Color Fade No function 3-255 Color fade with increasing speed Red + Green Color Fade No function 3-255 Color fade with increasing speed Red + Blue Color Fade No function 3-255...
  • Page 12 Manual | SquareLED LED MATRIX 16X30W COB BLINDER Red (1, 5, 9, 13) 0-255 0-100% Green (1, 5, 9, 13) 0-255 0-100% Blue (1, 5, 9, 13) 0-255 0-100% Red (2, 6, 10, 14) 0-255 0-100% Green (2, 6, 10, 14)
  • Page 13 Manual | SquareLED LED MATRIX 16X30W COB BLINDER Blue (11, 12, 15, 16) 0-255 0-100% Red (3, 4, 7, 8) 0-255 0-100% Green (3, 4, 7, 8) 0-255 0-100% Blue (3, 4, 7, 8) 0-255 0-100% Red (1) 0-255 0-100%...
  • Page 14 Manual | SquareLED LED MATRIX 16X30W COB BLINDER Green (6) 0-255 0-100% Blue (6) 0-255 0-100% Red (7) 0-255 0-100% Green (7) 0-255 0-100% Blue (7) 0-255 0-100% Red (8) 0-255 0-100% Green (8) 0-255 0-100% Blue (8) 0-255 0-100%...
  • Page 15 Manual | SquareLED LED MATRIX 16X30W COB BLINDER Red (13) 0-255 0-100% Green (13) 0-255 0-100% Blue (13) 0-255 0-100% Red (14) 0-255 0-100% Green (14) 0-255 0-100% Blue (14) 0-255 0-100% Red (15) 0-255 0-100% Green (15) 0-255 0-100%...
  • Page 16 Manual | SquareLED LED MATRIX 16X30W COB BLINDER Blue (2) 0-255 0-100% Red (3) 0-255 0-100% Green (3) 0-255 0-100% Blue (3) 0-255 0-100% Red (4) 0-255 0-100% Green (4) 0-255 0-100% Blue (4) 0-255 0-100% Red (5) 0-255 0-100%...
  • Page 17 Manual | SquareLED LED MATRIX 16X30W COB BLINDER Green (9) 0-255 0-100% Blue (9) 0-255 0-100% Red (10) 0-255 0-100% Green (10) 0-255 0-100% Blue (10) 0-255 0-100% Red (11) 0-255 0-100% Green (11) 0-255 0-100% Blue (11) 0-255 0-100%...

  • Page 18: Red (13, 14, 15, 16)

    Manual | SquareLED LED MATRIX 16X30W COB BLINDER Blue (15) 0-255 0-100% Red (16) 0-255 0-100% Green (16) 0-255 0-100% Blue (16) 0-255 0-100% DMX Channel (24CH) Channel Value Function Red (1, 2, 3, 4) 0-255 0-100% Green (1, 2, 3, 4)
  • Page 19 Manual | SquareLED LED MATRIX 16X30W COB BLINDER Green (1, 5, 9, 13) 0-255 0-100% Blue (1, 5, 9, 13) 0-255 0-100% Red (2, 6, 10, 14) 0-255 0-100% Green (2, 6, 10, 14) 0-255 0-100% Blue (2, 6, 10, 14)
  • Page 20 128-255 Sound control LED rangement 5. Specifications Model number: SquareLED LED MATRIX 16X30W COB BLINDER WHITE Input Voltage: AC100V - 240V 50 Hz/60Hz Lamp resource: 16 pcs 30W RGB LED Control model: Auto, sound, DMX512 signal Max temperature: 104°F (40°C) Outside size: 360x385x190 mm N.W: 10 kg...
