Summary of Contents for Squareled PQ1036
- Page 2 Manual | PQ1036 | 1. Summarize PQ1036 - LED PAR 36*10w RGBW Quad-color 4 in 1 LED Summarize Thank you for purchasing our LED PAR lighting. Please read these instructions carefully before begin and operate the fixtures according to these instructions to avoid any possible damages and accidents causes by misusage.
-
Page 3: Safety Information
Safety Information Safety Notes ! Enquire the skilled people before any repair; ! Always make sure disconnect from the power source before setting up, serving and moving;. ! Avoid direct eye exposure to the fixture when it is on; Safety instruction »... -
Page 4: Outside Size Picture
Outside Size Picture... - Page 5 2. DMX512 Channel Description Order number Item Quantity Remarks Order number Item Quantity Remarks Front cover Power main board bracket Glass Main board Glass waterproof Display platen silicone Lens plate display Lamp panel Silica gel tabletting bulb holder waterproof silicone bracket 1 set 2PCS...
-
Page 6: Main Function
Main Function » Protection rating:IP65,in-door or out-door use » unique cooling mode: natural convection » DMX512 Controller, 4 button set DMX ID address with led display » master slave/interconnected multi-machine control » lens degree: 25º, 45º optional » using switching power supply to protect the LED to work well »... -
Page 7: Display Operation
DMX Control Function »8CH Channel DMX Value Control Function Remark 0-255 General dimming 0-255 Red Dimming 0——100% 0-255 Green Diming0——100% 0-255 Blue Dimming 0——100% 0-255 White 0——100% 0-14 Dimming When the 7CH above31, this function is invalid 15-255 Strobe Speed 0-31 Invalid 32-63... -
Page 8: Manual Instruction
Manual Instruction... - Page 9 Operations: 1. MENU is used to access the menu or return to a previous menu option. It can not be used to select and store the current menu option. Press UP / DOWN to choose a desired menu item. Here are the operation details: »...
-
Page 10: Operating Control Instruction
»Press UP/DOWN, until shows “CHNd” »Press ENTER to access the menu items to select, the screen will now be glinting »Press UP/DOWN to change the DMX Channel: 3CH, 4CH, 5CH, 8CH » At last, press ENTER to confirm, if it delay for 3 seconds, DMX channel choosing will be saved, and go back to DMX receive mode(A001);... -
Page 11: Xlr Cable Connecting
XLR cable connecting XLR cable The standard connection way of the XRL is: one end connect to the male plug ,and the other connect to the female. Noted: In order to avoid failures and interference signal transmission, we connect a resistance120Ω... -
Page 12: Connecting Picture
Connecting picture: Light connecting picture Connecting picture: Great waterproof PAR lamp wiring diagram... -
Page 13: Problem Analyse
Problem Analyse Problem Checking way Check the power source plug is in normal or not Check the switch of the lights is off or on Can not turn on the light Check the fuse if in normal Check the DMX cable is connect to the lights or not Check the DMX512 controller work in normal or not DMX can not control it Check the DMX cable is normal or not... -
Page 14: Technical Specification
Technical Specification » Input voltage: AC 90-135V/47-63HZ AC 170V-264V/47-63HZ »Output voltage: DC24V »Consume: 350W »Lamp Type: High Power LED(10w) »Lamp Spec: RGBW 4-in-1 LED(36 pcs) »Constant current drive: 500mA »Refresh Rate: 400HZ »Life Span: 50000~100000 hours »Control Signal: DMX512, master and slaver »Control mode: stand alone/ DMX/ master and slaver »Channel: 3,4,5,8 CH »Function Effect: dimmer, strobe, eotic, gradual change... - Page 15 Das Lichttechnikhaus Vertriebs GmbH Rudolf-Diesel-Str. 3, D-89312 Günzburg Telefon +49 (0) 82 21 207 98-0 +49 (0) 82 21 207 98-69 E-Mail info@lth-gmbh.de www.lth-gmbh.de...
