- Page 2 Product introduction LED PQ818 light uses aluminum shell, designed in a fashion of hydrodyna- mic form. Appearance shows: long can, short can or short can with color filter. It adopts high power 4-in-1 LED, which refers to single LED is made of R,G,B,W LED, And long life span, low consumption, good color mixing effect and high brightness are the most prominent features.
- Page 3 Manual | PQ818 | 2. Safety Information Safety Notes ! Enquire the skilled people before any repair; ! Always make sure disconnect from the power source before setting up, serving and moving;. ! Avoid direct eye exposure to the fixture when it is on;...
- Page 4 Manual | PQ818 | 3. Outside Size Picture...
- Page 5 Built-in temperature control function: The output of LED will be reduced when LED is too hot. » lens degree: 15º 25º 45º optional » Protection grade: IP65 » DMX Channel, Optional Manual | PQ818 | 5. DMX Control Function » DMX Channel (3CH) Channel DMX Value Control Function Remark 0-255...
- Page 6 Manual | PQ818 | 5. DMX Control Function » DMX Channel (5CH) Channel DMX Value Control Function Remark 0-255 General dimming 0-255 R 0-100% 0-255 G 0-100% 0-255 B 0-100% 0-255 W 0-100% »DMX Channel (8CH) Channel DMX Value Control Function...
- Page 7 Manual | PQ818 | 6. Display Operation » MENU : access the menu or return to a previous menu option » ENTER: select the current menu option » UP: menu selection or parameter increments » DOWN: menu selection or parameters decrease...
- Page 8 Manual | PQ818 | 7. Menu Instruction...
- Page 9 Manual | PQ818 | 7. Menu Instruction 1. Operating instruction: MENU (UP/DOWN)+ENTER+(UP/DOWN)+ENTER Remark: Exp: Select the DMX mode, Here are the operation details: » Press the MENU, go back to the initial setting » Press UP/DOWN, display “Addr” » Press ENTER to change the content, the display will glinting at this moment »...
- Page 10 Pr29: 4 colors jumping. » Pr30: there are kinds of colors jumping Manual | PQ818 | 8. Operating Control Instruction Master/Slave Master: The master should always work as a master as long as it is not set in a DMX mode whatever other modes it is.
- Page 11 Manual | PQ818 | 9. XLR cable connecting XLR cable The standard connection way of the XLR is: one end connect to the male plug ,and the other connect to the female.As bellow:pin 1:ground,pin 2: negative signal,pin 3: positive Noted: In order to avoid failures and interference signal transmission，we connect a resistance 120Ω...
- Page 12 Manual | PQ818 | 10. Connecting picture: Light connecting picture Manual | PQ818 | 11. Trouble Shooting Problem Checking way Check the power source plug is in normal or not Can not turn on the light Check the switch of the lights is off or on...
- Page 13 Manual | PQ818 | 12. Technical Specification » Input voltage: AC 100V-264V/47-63HZ » Output voltage:DC24V » Consume:120W » Lamp Type:4-in-1 LED » Lamp Spec: High Power 8W 18PCS » Constant current driver:500MA » PWM Dimmer: >400HZ(16666 grades) » Refresh rate:>400HZ »...
- Page 14 Das Lichttechnikhaus Vertriebs GmbH Rudolf-Diesel-Str. 3, D-89312 Günzburg Telefon +49 (0) 82 21 207 98-0 +49 (0) 82 21 207 98-69 E-Mail info@lth-gmbh.de www.lth-gmbh.de...
