- Page 1 Grundig SAT Syst ms Head-End Receiver Converter HRC 300 AV C LASS CLASS Phone: +49 (0) 911 / 703 8877 Grundig SAT Systems GmbH Fax: +49 (0) 911 / 703 9210 Beuthener Strasse 43 E-mail: info@gss.de D-90471 Nuremberg Internet: http://www.gss.de...
-
Page 2: Table Of Contents
Contents 1 Safety regulations ....................3 2 General information .................... 4 2.1 Scope of delivery ................... 4 2.2 Meaning of the symbols used ..............4 2.3 Technical specifications ................4 2.4 Description ................... 5 2.4.1 Display of the control unit software version ........5 3 Installation ...................... -
Page 3: Safety Regulations
• Test the software versions of the head-end station and the cassette and update them if necessary. The current software versions can be found at ”www.gss.de”. Take action to prevent static discharge when working on the device. Electronic devices should never be disposed of in the household rubbish. -
Page 4: General Information
General information 2.1 Scope of delivery 1 HRC 300 AV cassette 1 CD (assembly instructions) 1 Brief assembly instructions 2.2 Meaning of the symbols used Important note —> General note • Performing works 2.3 Technical specifications The requirements of the following EU directives are met: 2006/95/EC, 2004/108/EC The product fulfils the guidelines and standards for CE labelling. -
Page 5: Description
“V 40” or higher. You can find the current operating software for the control unit and the cassette, the software “BE-Flash” and the current assembly instructions on the website “www.gss.de”. The cassette is designed for use in the following head-end stations: –... -
Page 6: Installation
Installation 3.1 Installing the cassette – Ensure the head-end station is mounted so it will not be able to vibrate. Avoid, for example, mounting the head-end station onto a lift shaft or any other wall or floor construction that vibrates in a similar way. –... -
Page 7: Overview Of The Cassette
• Insert the required number of cable terminals in the openings provided in the head-end station or in the 19” cabinet. —> Cable terminals are not included in the scope of delivery. Tighten the nuts on the cable terminals until the teeth on the lock washers have penetrated the exterior coating and a good connection is made between the housing and cable terminal. -
Page 8: Connecting The Cassette
The operating software of the cassette can be updated via the 9-Pin D-SUB socket “RS 232” using a PC or notebook and the software “BE-Flash”. You can find the current operating software on the website “www.gss.de”. 3.4 Connecting the cassette •... -
Page 9: Control Panel
4.2 Control panel The key pad on the head-end station is used to scroll through the menus step- by-step: scrolls forward through the menus. ◀ ▶ select parameters in the menus. set values, initiate actions. selects sub-menus. AUDIO scrolls backward through the menus. saves all entries. -
Page 10: Programming Procedure
5.2 Programming procedure Ein / On BE–Remote V 40 please wait … t > 10 s Box 1 Box 2 ....– – – ......Bx 1A Kanalzüge ”A” / ”B” / ”C” Channel strips ”A” / ”B” / ”C” Bx 1A MODULATOR Level... -
Page 11: Programming The Cassette
5.3 Programming the cassette —> Pressing the button for longer than 2 seconds cancels the pro- gramming procedure. This takes you back to the program item “Selecting the cassette” from any menu. Any entries that have not been saved are reset to the previous settings. -
Page 12: Selecting The Channel Strip
• Press the button. —> The “Selecting the channel strip” – “Bx 1A” menu is activated. Selecting the channel strip Bx 1A Kanalzüge ”A” / ”B” / ”C” Channel strips ”A” / ”B” / ”C” • Use to select the channel strip (modulator) “A”, “B” or “C“... -
Page 13: Setting The Hf Output Level
Setting the HF output level In this menu you can set the HF output levels of the channel strips “A”, “B” and “C” to the same values and switch on or off the modulator of the channel strip. Bx 1A MODULATOR Level 0 …... -
Page 14: Selecting Channel / Frequency Setting
• Press the button. —> The “Selecting channel / frequency setting” / “Set- ting the TV standard of the output signal” – “NORM” menu is activated. Selecting channel / frequency setting In this menu, you can select the channel or frequen cy set- ting for the adjustment of the HF output. -
Page 15: Setting The Output Channel
Setting the output channel Bx 1A OUTPUT Bx 1A OUTPUT Fine - 64 … + 63 • Use to set the output channel of the modulator. Setting the fine tuning Adjust the fine tuning (frequency offset) only in individual cases which give you reason to do so (e. g. moiré, interferenc- es), since all TV sets connected to the cable system have to be fine tuned after making changes. -
Page 16: Setting The Audio Type
Setting the audio type In this menu you can set the audio type in which the modula- tor is to modulate the audio signals. If a mono audio signal (white Cinch socket) is fed in into a channel strip, program the respective channel strip to “Mono L”. -
Page 17: Saving Settings
Saving settings • Press the button. —> The settings are saved. —> You return to the “Selecting the cassette” menu via connection (page 11). —> By pressing the button, you will be returned to the menu item “Selecting the channel strip” via connection without saving the programmed data (page 12). -
Page 18: Channel And Frequency Tables
C 61 791.25 C 34 575.25 C 48 687.25 C 62 799.25 Service: Phone: +49 (0) 911 / 703 2221 Fax: +49 (0) 911 / 703 2326 Email: service@gss.de Alterations reserved. Technical data E. & O.E. © by GSS GmbH 29062009...
