GSS HDMT 1000 SPTS Assembly Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HDMT 1000 SPTS

Advertisement

Table of Contents
loading

Related Manuals for GSS HDMT 1000 SPTS

Summary of Contents for GSS HDMT 1000 SPTS

  • Page 1 HDMT 1000 SPTS...

  • Page 2: Table Of Contents

    o n t e n t s 1 Safety regulations and notes ................4 2 General information ..................5 Packing contents ................5 Meaning of the symbols used ............... 5 Technical specifications ............... 5 Description ..................7 Software query .................. 8 3 Assembly ......................9 Installing the cassette ................9 EMC regulations ................
  • Page 3 Setting the transmission channel ............ 26 Copying the settings to all IP addresses .......... 26 Setting IP addresses for services ............ 27 Allocating IP addresses to services manually ........27 Allocating IP addresses to services automatically ......27 Allocating services manually ............28 Selecting the sound options of the service ........

  • Page 4: Safety Regulations And Notes

    a f e t y r e g u l a t i o n s a n d n o t e s • Assembly, installation and servicing should be carried out by authorised electricians. • Switch off the operating voltage of the system before beginning with assem- bly or service work or pull out the mains plug.

  • Page 5: General Information

    2.1 P aC k i n g C o n t e n t s 1 Cassette HDMT 1000 SPTS 2 RF cables 1 Brief assembly instructions 2.2 m...
  • Page 6 ASI interfaces Standard: ..............DIN EN 50083-9 Format: ..............MPEG ISO IEC 13818-1 User data rate: ..............2 … 90 Mbit/s Impedance: ..................75 Ω Level (input / output): .............800 mV ± 10% Return loss (input):..........> 17 dB (5 … 270 MHz) Connections RF inputs: ................2 IEC sockets RF loop-through outputs: ............2 IEC sockets RF output: ............1 IEC socket (no function) LAN: ................

  • Page 7: Description

    2.4 d es C r i P t i o n The cassette is a DVB-T / SPTS converter which combines COFDM-modulated services (programmes) and transport streams supplied via the ASI interface into one transport stream in the TPS module. This is emitted via the LAN inter- face and can contain up to 16 services.

  • Page 8: Software Query

    Two LEDs in the channel strips provide an indication with their colour whether an RF signal is present or not. In a menu, the transmission of DVB service in- formation (EIT, TDT and SDT) or teletext (TXT) can be individually activated or deactivated.

  • Page 9: Assembly

    s s e m b l y 3.1 i n s ta l l i n g t h e C a s s e t t e – Ensure the head-end station is mounted so it will not be able to vibrate. Avoid, for example, mounting the head-end station onto a lift shaft or any other wall or floor construction that vibrates in a similar way.

  • Page 10: Emc Regulations

    3.2 emC r e g u l at i o n s To comply with the current EMC regulations, it is necessary to connect the lines leading in and out of the head-end station using cable terminals. When mounting the cassette in a head-end station which is installed in a 19" cabinet, make sure the connections leading in and out for the 19" cabinet are made using cable terminals. The attenuation of shielding of the connection lines for ASI and antenna must meet the requirements for "Class A". CLASS • Insert the required number of cable terminals in the openings provided in the head-end station or in the 19" cabinet. Tighten the nuts of the cable terminals until the teeth on the lock washers put un- der have penetrated the exterior coating and a good connection is made between the housing / 19" cabinet and cable terminals.

  • Page 11: Overview Of The Cassette

    3.3 o v e rv i e w t h e C a s s e t t e RF input (channel strip "B") Status LED of the channel strip "B" Loop-through output of RF input RF input (channel strip "A") Status LED of the channel strip "A"...

  • Page 12: Updating The Software

    3.5 u P dat i n g t h e s o f t wa r e The RS 232 interface of the cassette enables you to use a PC or a notebook and the "BE-Flash" software to update the software of the cassette. You can find the "BE-Flash"...

  • Page 13: Retrofitting A Ca Module

    3.6 r Ca e t r o f i t t i n g m o d u l e The cassette is equipped with a common interface. It allows you to connect a CA module for various encryption systems and service providers. Scrambled services can only be descrambled with a CA module suitable for the scram- bling system and the corresponding smart card.

  • Page 14: The Control Panel At A Glance

    C o n t r o l P a n e l g l a n C e 4.1 m e n u i t e m s Program the cassette using the buttons on the control unit of the head-end sta- tion.

  • Page 15: Programming

    r o g r a m m i n g 5.1 P ro g r a m m i n g Pro C e d u r e Ein / On BE–Remote V 45 please wait … t > 10 s Box 1 ……...
  • Page 16 on / off PID Check Bx 4A Menu <= => Edit X / 0 ◀ ▶ Bx 4A TV 01/06 X – entschlüsseln descrambling ..0 – nicht entschlüsseln no descrambling ◀ ▶ Bx 4A 01/03 MENU nächster Service next service Information *)

  • Page 17: Programming Procedure

    5.2 P r o g r a m m i n g t h e C a s s e t t e —> Pressing the button for longer than 2 seconds cancels the programming procedure. This takes you back to the program item "Selecting the cassette"...

  • Page 18: Selecting The Cassette, Displaying The Software Version

    e l e C t i n g t h e C a s s e t t e d i s P l ay i n g t h e s o f t wa r e v e rs i o n Box 1 ……...

  • Page 19: Ip Address Of The Cassette

    a d d r es s t h e C a s s e t t e If you choose to enter the Ethernet parameters manually, set the IP address of the cassette in this menu. If "DHCP" is selected, the "IP-ADDR", "IP-MASK" and "IP-GATEWAY"...

  • Page 20: Address Of The Gateway

    d d r es s t h e gat e way The address of a gateway (server) can be set in this menu. If no gateway is used you can skip this setting. Bx 4 IP-GATEWAY 192.168. • Use the buttons to place the cursor under the digit of the IP address displayed to be set and use to set the desired IP address.

  • Page 21: Input Transport Stream

    n P u t t r a n s P o r t s t r e a m In this menu you select the signal source for the selection of the services. The transport streams to be processed are provided by "Tuner A", "Tuner B" and the ASI interface "ASI".
  • Page 22 —> "0" is displayed instead of the frequency display. Bx 4A INPUT -64…+64 • Use for fine tuning the input channel ("-64" … "+64"). In addition to the indicator in the display, there is also a status LED which indi- cates whether a transport stream is received or not: LED indicator Indication Green...

  • Page 23: Setting The Hierarchical Modulation

    e t t i n g t h e h i e r a rC h i C a l m o d u l at i o n In order to attain with less field strength a greater range for broadcasters, with DVB-T so-called "hierarchical modulation"...

  • Page 24: Allocating The Ip Addresses

    iP l lo C at i n g t h e a d d r es s es In this menu up to 16 services that are contained in the data streams of the in- put source signals ("Tuner A", "Tuner B", "ASI") can be accessed. The services detected receive an IP address automatically.

  • Page 25: Switching The Ip Address Off Or On

    Switching the IP address off or on • Press the buttons to switch off ("off") or ("on") the output IP address and the service referred. —> In the second line of the "IP-OUT …" menu "off" is displayed in- stead of the service referred. Bx 4 IP-OUT 1 =>...

  • Page 26: Defining The Quantity Of Data Packets

    e f i n i n g t h e q ua n t i t y data PaC k e t s e t t i n g t h e f o rwa r d e r r o r C o r r e C t i o n e t t i n g t h e...

  • Page 27: Setting Ip Addresses For Services

    • Press the button. —> The "Setting IP addresses for services" – "OUT-IP" menu is activated. iP e t t i n g a d d r es s es f o r s e rv i C es In this menu you set the IP address for the IP output selected. The software al- lows to allocate IP addresses to 16 services automatically in ascending order after setting the IP address.
  • Page 28 l lo C at i n g s e rv i C es m a n ua l ly In this menu all services (programmes) supplied via "Tuner A", "Tuner B" and "ASI" can be displayed and each service is assigned a set IP address in the "OUT-IP"...

  • Page 29: Selecting The Sound Options Of The Service

    If no service is found the display shows "– – –" instead of the name of the service. In this case check the configuration of the antenna system including the head-end station and the previous settings of the cassette as well as the components connected to the ASI input.

  • Page 30: Displaying The Output Data Rate

    • Using the buttons activate ("EIT", "TDT", "TXT", "SDT") or deactivate ("eit", "tdt", "txt", "sdt") the transmission option wished. —> Activated options are shown with capital letters, deactivated with small letters. Copying the settings to all IP addresses • Pressing the button the settings can be copied to all IP addresses. —>...
  • Page 31 aC to ry r es e t In this menu you can reset all settings to the factory defaults. Werkeinstellwerte Bx 4A FACTORY Bx 4A FACTORY aufrufen ▶ invoke factory defaults Defaults => STORE => M • Press the button. —>...

  • Page 32: Configuring The Ca Module

    Ca P e r at i o n w i t h m o d u l e In order for this function of the CA module to be possible, in the "Selecting the input data stream" – "INPUT" menu (page 21) an input signal source must be selected whose data stream contains services which can be descrambled by the CA module you are using and your smart card.

  • Page 33: Descrambling Services

    —> By pressing the button you can skip the "Configuring the CA module" – "CA" menu and activate the "Selecting the input data stream" – "INPUT" menu (page 21). • Press the button to activate the menu of the CA module. —>...
  • Page 34 es C r a m b l i n g s e rv i C es In this menu you select the services wished from the scrambled data stream, which are to be descrambled. Bx 4A Menu <= => Edit Bx 4A 01/03 Bx 4A 01/03 MENU...
  • Page 35 i n a l Pro C e d u res After installing the head-end station, upgrading accessories or installing cas- settes it is necessary to tighten all cable connections, cable terminals and cover screws in order to maintain compliance with current EMC regulations securely. • Securely tighten the cable bolted connections using an appropriate open- ended spanner. • Mount the front cover (see assembly instructions of the head-end station). - 35 - HDMT 1000 SPTS...
  • Page 36 Declaration of CE conformity GSS Grundig SAT Systems GmbH • Beuthener Straße 43 • D-90471 Nuremberg Phone: +49 (0) 911 / 703 8877 • Fax: +49 (0) 911 / 703 9210 www.gss.de/en • info@gss.de CLASS CLASS Service: Phone: +49 (0) 911/703 2221; Fax: +49 (0) 911/703 2326; service@gss.de Alterations reserved.
