Adjust the tilt angle of your monitor

1. To change the angle that the monitor is tilted at, use the 6 mm hex key to turn the
screw in the side of the VESA monitor mount counterclockwise.
2. When the screw is loose, position the monitor at the angle that works best for you.
3. Use the 6 mm hex key to turn the screw clockwise to tighten it. (figure 13)
figure 13
VESA monitor mount
6 mm hex key
4. When you're done adjusting the tilt angle, you can store the hex keys in the hex key
holder in the cable-management clip. (figure 14)
figure 14
Cable-management clip
