StarTech.com ARMPIVOTV2 Manual page 14

3. Remove the backing from the five rubber pads and affix them to the underside of
the grommet collar. (figure 5)
figure 5
Grommet collar
4. Position the grommet collar over the grommet hole in the mounting surface, and
position the pole over the grommet collar so that the projection on the grommet
collar fits into one of the two holes on the pole. (figure 6
figure 6
Pole
Grommet collar
Instruction manual
Rubber pad
10
Projection
