Spectralink IP-DECT Server 200/400/6500 and Virtual IP-DECT Server One Installation and Configuration Guide

Administration - Base Station - Base Station

Field
Base Station - General
IP address (Read only)
Description (Optional)
RPN
Site
Disabled (Optional)
TX power (Optional)
14215700-IG, Edition 15.0
May 2020, Original document
Current IP address of the base station.
Enter a description.
It is recommended to use a description of the physical loc-
ation.
Radio Part Number of the base station.
Note: If using zone based paging, assigning base stations
and RPN's are essential, as the RPN decides which zone the
Spectralink IP-DECT Base Station will be part of. For more
information, see "Example of Defining Sites, Zones and
Assigning Numbers to Base Stations" on
If using radio based synchronization in connection with zone
based paging, RPN's must be assigned to the relevant zones
before defining synchronization chain.
Default value: None
It is possible to define sites for devices that are located at the
same location.
To assign a site to the base station, select the relevant site
from the list.
For information about defining sites, see
the Media Resource and Base Stations" on
If enabled, the base station will be disabled.
Note: If Add new as active is enabled (Configuration >
Wireless Server > Base stations), then this will be unset
by default when adding a new base station.
Used for controlling the output power for this specific base
station.
Select another value from the list, if you need to change the
output power.
Default value: Default (250 mW). If
the default value is 100 mW.
Note: If a system TX power other than default is set for the
whole system (Configuration > Wireless Server > DECT),
that setting will override this setting.
page 163.
"Defining a Site for
page 177.
Frequency is set to USA,
411
