Egholm Park Ranger 2150 Operator's Manual

Snow sweeper
Hide thumbs Also See for Park Ranger 2150:
Table of Contents

Advertisement

Quick Links

Download this manual
Operator´s
manual
Snow Sweeper
Park Ranger 2150

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Park Ranger 2150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Egholm Park Ranger 2150

Summary of Contents for Egholm Park Ranger 2150

  • Page 1 Operator´s manual Snow Sweeper Park Ranger 2150...
  • Page 2 Dear Customer Congratulations with your new Egholm product The Park Ranger 2150 is a Danish designed and manufactured utility machine, which allows you to take a very flexible approach to maintaining outdoor areas. Optimal use of your Park Ranger 2150 Snow sweeper To ensure the optimal performance of your Park Ranger 2150 snow sweeper, please read this operator’s manual carefully before starting to use the machine.

  • Page 3: Table Of Contents

    5.1 Wearing parts – Park Ranger 2150 snow sweeper ....... .

  • Page 4: General Information

    General information...

  • Page 5: Safety

    General information 1.1 Safety Make sure no-one is standing close to the machine while it is in use Make sure that no one is near the Ophold i knækområdet machine while it is in use as there is er forbudt a danger of crushing.

  • Page 6: Ec Declaration Of Conformity

    · has been manufactured in conformity with the provisions of the Machinery Directive, Directive 2006/42/EU The Park Ranger 2150 fitted with the FH 2100 cab (ROPS approved) · has been tested at the Danish Institute of Agricultural Sciences at Bygholm in conformity with directive 86/298/EEC concerning rear mounted, roll-over protection structures of narrow-track wheeled agricultural and forestry tractors.

  • Page 7: Technical Data

    General information 1.3 Technical data Dimensions Attached Storage dimensions Length (L) 3,020 mm 900 mm Width (W) 1,220 mm 1,220 mm Height with cab 1,935 mm Height 650 mm Technical data Type 21SK1205 Clearing width 1,140-1,220 mm Ground clearance below brush 420 mm Brush diameter 550 mm...

  • Page 8: Operator's Manual

    Operator´s manual...

  • Page 9: Assembly / Disassembly

    Operator’s manual 2.1 Assembly / Disassembly 1. We recommend that you run the hydraulic hoses over the snow sweeper guard to keep them clear and free from dirt when the snow sweeper is fitted. (Picture 1) 2. The locking handle on the A-frame of the base machine must be in the open position.

  • Page 10: Before Start-Up

    Operator’s manual 2.1 Assembly / Disassembly 9. Pull out the locating pin and swivel the support strut in front of the wheel on the machine until it falls into place. (Picture 1+2) 10. Attach the hydraulic hoses which are used to turn the snow sweeper to the B-connector on the left-hand side of the machine.

  • Page 11: Start-Up

    Operator’s manual 2.3 Start-up 1. Start the machine. 2. Lower the snow sweeper by pushing lever A on the left-hand side of the machine down to A B C position 2. (Picture 1) 3. We recommend that you hold the lever down for about 2 seconds, as this will place the snow Lever A Lever B...
  • Page 12 Operator’s manual 2.3 Start-up - Continued When turning, the rear of the machine swings out so there is a risk of crushing or collision. We recommend that you do not drive with a higher engine speed than necessary, to reduce the noise and the energy consumption.

  • Page 13: Service And Maintenance

    Service and maintenance...
  • Page 14 5. Fit a flat brush ring to finish. 6. Replace the flange. New brush rings can be ordered from an authorised Egholm distributor. Storage outside the season When the snow sweeper is to be stored outside the season, we recommend that you remove any loose paint and to repaint any damaged areas.

  • Page 15: Conditions

    Conditions...

  • Page 16: Warranty

    The warranty period for the materials and manufacture of the snow sweeper is 12 months from the date of purchase. In case of faults or defects in the machine within the warranty period, Egholm will carry out the necessary repairs without charge for materials and working hours in accordance with the terms and conditions listed below.

  • Page 17: Complaints

    We wish you many years of safe and satisfactory use of your machine. Best regards Egholm A/S 4.3 Disposal When many years from now your snow sweeper comes to the end of its working life, it should be disposed of in a responsible manner and conform with the relevant disposal regulations.

  • Page 18: Wearing Parts

    Wearing parts...

  • Page 19: Wearing Parts - Park Ranger 2150 Snow Sweeper

    Wearing parts 5.1 Wearing parts – Park Ranger 2150 snow sweeper 01109000 Spacer 90501911 Brush ring set 09701390 Wheel for support strut 09722670 Rubber cover Operator’s Manual City Ranger 2150 Snow Sweeper...

  • Page 20: Notes

    Notes Operator’s Manual City Ranger 2150 Snow Sweeper...
  • Page 21 Notes Operator’s Manual City Ranger 2150 Snow Sweeper...
  • Page 22 Egholm A/S Transportvej 27 7620 Lemvig, Denmark T.: +45 97 81 12 05 www.egholm.eu - info@egholm.dk...
