Egholm Park Ranger 2150 Operator's Manual

Hide thumbs Also See for Park Ranger 2150:
Table of Contents

Advertisement

Quick Links

Download this manual
O
'
peratOr
s manual
HEDGE TRIMMER
Park Ranger 2150

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Park Ranger 2150 and is the answer not in the manual?

Questions and answers

Related Manuals for Egholm Park Ranger 2150

Summary of Contents for Egholm Park Ranger 2150

  • Page 1 ’ peratOr s manual HEDGE TRIMMER Park Ranger 2150...
  • Page 2 Reservations: As it is the Egholm policy to make continuous improvements, we reserve the right to alter the machine’s specifications and equipment at any time without notice. Egholm accepts no liability for errors or omissions in the operator’s manual.

  • Page 3: Table Of Contents

    5.1 Wearing Parts - Park Ranger 2150 hedge trimmer ....... .

  • Page 4: General Information

    Do not drive on slopes with an incline of more than 10° The tyre pressure must be checked and adjusted to 1.5 bar (22 psi) when the Hedge trimmer is attached. Low tyre pressure increases the risk of roll-overs. (Picture 3) Operator’s Manual – Park Ranger 2150 Hedge trimmer...

  • Page 5: Ec Declaration Of Conformity

    Elkær Maskiner Model: HK 1300 MINI / 2200 Type: · has been manufactured in conformity with the provisions of the Machinery Directive, Directive 2006/42/EC Place: Lemvig, Denmark Date: Signature: Knud Olsen, Senior Engineer Operator’s Manual – Park Ranger 2150 Hedge trimmer...

  • Page 6: Technical Data

    270º Max. branch thickness 20 mm Operating speed 1-3 km/h Weight 130 kg Hydraulic oil Texaco Rando HDZ 46 or equivalent Specifications may be changed without prior notice. Information plate: (Picture 1) Operator’s Manual – Park Ranger 2150 Hedge trimmer...

  • Page 7: Operator's Manual

    3. Raise the A-frame using lever A on the left-hand side of the base machine until the hedge trimmer is freely suspended above the ground. (Picture 4) Support strut lowered 4. Switch off the engine. Locking Lever D Operator’s Manual – Park Ranger 2150 Hedge trimmer...
  • Page 8 To avoid accidents when detaching the hedge trimmer, always make sure the machine is on a level and stable surface. Put the protective caps on the snap couplings to protect them from dirt. Support strut up Operator’s Manual – Park Ranger 2150 Hedge trimmer...

  • Page 9: Before Start-Up

    Operator’s manual 2.2 Before start-up During transport: Lock the hedge trimmer in the raised position using the transport lock. This prevents the attachment from lowering inadvertently during transport. Transport lock in locked position Operator’s Manual – Park Ranger 2150 Hedge trimmer...

  • Page 10: Start-Up

    4. Lower the hedge trimmer by pushing lever A on the left- hand side of the machine down to position 2. (Pictures 3 and 4) Lever D A B C Lever A Lever B Wheels on surface Operator’s Manual – Park Ranger 2150 Hedge trimmer...
  • Page 11 Operator’s manual Make sure no one is standing close to the machine while it is in use. Operator’s Manual – Park Ranger 2150 Hedge trimmer...

  • Page 12: Setting Trimmer Position

    1. Activate Lever B until the cutting bar reaches the required position. 2. To trim at higher horizontal/vertical positions: Activate Lever C to move the cutting arm upwards. Use Lever B to reposition the cutting bar. Cutting arm Cutting arm Operator’s Manual – Park Ranger 2150 Hedge trimmer...
  • Page 13 Tips! Reach Boom adjustment If a long side-reach is required, tilt the boom to the side where trimming is to be done. (Picture 4) Locking pin Arm to right Operator’s Manual – Park Ranger 2150 Hedge trimmer...
  • Page 14 The cutting bar is then raised higher up the hedge, so that the same section is trimmed all the way to the top. (Picture 1) Operating speed Depending on the conditions, an operating speed of 1–3 km/h is recommended. Operator’s Manual – Park Ranger 2150 Hedge trimmer...

  • Page 15: Service And Maintenance

    Defective blades must be replaced immediately. This ensures effective trimming and reduces wear and tear on the hedge trimmer. Blade replacement must only be carried out by an authorised Egholm dealer Lubricating nipples Operator’s Manual – Park Ranger 2150 Hedge trimmer...

  • Page 16: Conditions

    The warranty period for the materials and manufacture of the hedge trimmer is 12 months from the date of purchase. In case of errors or defects on the machine within the warranty period, Egholm will carry out the necessary repairs at no charge for materials and working hours in accordance with the terms and conditions listed below.

  • Page 17: Complaints

    2. Remove the plastic and rubber parts and dispose of them in accordance with the applicable environmental legislation. 3. After the parts mentioned have been removed, the machine is ready to be handed over to an approved scrap merchant. Operator’s Manual – Park Ranger 2150 Hedge trimmer...

  • Page 18: Wearing Parts

    Wearing parts 5.1 Wearing Parts - Park Ranger 2150 hedge trimmer 90601370 Complete blade set 90601050 Blade tooth 90601060 Rivet 90601410 Complete upper blade 90601420 Complete lower blade 01100330 Wheel 90601030 Knife guide 02901080 Lubricant spray 90601100 Skid Operator’s Manual – Park Ranger 2150 Hedge trimmer...

  • Page 19: Notes

    Notes Operator’s Manual – Park Ranger 2150 Hedge trimmer...
  • Page 20 Egholm A/S Transportvej 27 DK-7620 Lemvig T. +45 97 81 12 05 F. +45 97 81 12 10 www.egholm.eu info@egholm.dk 90203181-01 EN...
