  • Page 1 LEAF SUCTION UNIT Park Ranger 2150...
  • Page 2 Reservations: As it is the Egholm policy to make continuous improvements, we reserve the right to alter the specifications and equipment at any time without prior notice. Egholm accepts no liability for errors or omissions in the operator’s manual.

  • Page 3: Table Of Contents

    Fine the hose retainer on the suction hose for the dust is led away from the user. sake of convenience. Operator’s Manual – Park Ranger 2150 Leaf Suction Unit...

  • Page 4: General Information

    Attachment lock in locked position an even, horizontal, solid surface. Máx. 10° Do not drive on slopes with an incline of more than 10° Operator’s Manual – Park Ranger 2150 Leaf Suction Unit...
  • Page 5 (Picture 3) Avoid ear injury: Use only approved hearing protectors when the machine is in use. (Picture 4) Use approved ear defenders Operator’s Manual – Park Ranger 2150 Leaf Suction Unit...

  • Page 6: Ec Declaration Of Conformity

    · has been manufactured in conformity with the provisions of the Machinery Directive, Directive 98/37/EC · is in conformity with the provisions of the following other EC directive: directive 2000/14/EC Place: Lemvig, Denmark Date: Signature: Knud Olsen, Senior Engineer Operator’s Manual – Park Ranger 2150 Leaf Suction Unit...

  • Page 7: Technical Data

    Capacity (leaf container on bogie trailer) 1200 liter Total weitht incl. suction mouth unit and leaf container on bogie trailer 726 kg (incl. cab): (842 kg) Specifications may be changed without prior notice. Operator’s Manual – Park Ranger 2150 Leaf Suction Unit...

  • Page 8: Operator's Manual

    Mate the locating pins/holes Warning: When mounting the leaf container and hose retainer, the rotating flash should be moved to the top position. Disassembly: Reverse the above procedure. Close the tipper/bogie trailer tailboard Operator’s Manual – Park Ranger 2150 Leaf Suction Unit...
  • Page 9 (Picture 4) Detaching: Reverse the above procedure. After use, remember to re-install the protective caps on the hose couplings. D-connectors The hoses are fastened with the rubber strap Operator’s Manual – Park Ranger 2150 Leaf Suction Unit...
  • Page 10 3. Place the rubber strap onto the hose retainer. Storing the remote vacuum hose Screw the bolt through the washer and into the hole Rubber strap, hose retainer, bolt and washer Operator’s Manual – Park Ranger 2150 Leaf Suction Unit...
  • Page 11 Detaching: Reverse the above procedure. Lock the hose holder in place with the hand-lever Hose clip Suction hose The plastic tube should be located in the leaf container aperture Operator’s Manual – Park Ranger 2150 Leaf Suction Unit...

  • Page 12: Before Start-Up

    Attention! Reduce noise levels and energy consumption by keeping engine revs as low as possible. Start the leaf suction unit with lever D Operator’s Manual – Park Ranger 2150 Leaf Suction Unit...

  • Page 13: Emptying The Leaf Container

    It is essential to locate the machine on a horizontal, flat surface, before attempting Emptying the container - shift lever C to empty the contents. Ensure the upwards machine is not in a turning position. Operator’s Manual – Park Ranger 2150 Leaf Suction Unit...

  • Page 14: Adjustments

    2. Adjust the suction mouth to the required height. 3. Tighten the handle. 4. Adjust to the same height on the other side, making the suction mouth parallel with the ground. 5. Tighten the handle. Operator’s Manual – Park Ranger 2150 Leaf Suction Unit...

  • Page 15: Service And Maintenance

    2. Detach the hydraulic hoses. 3. Remove the hose clip connecting the suction hose to the suction unit. 4. Unblock the suction hose manually. 5. To restore operation reverse this procedure. Operator’s Manual – Park Ranger 2150 Leaf Suction Unit...

  • Page 16: Conditions

    The warranty period for the materials and manufacture of the leaf suction unit is 12 months from the date of purchase. In case of errors or defects on the machine within the warranty period, Egholm will carry out the necessary repairs at no charge for materials and working hours in accordance with the terms and conditions listed below.

  • Page 17: Complaints

    2. Remove the plastic and rubber parts and dispose of them in accordance with the applicable environmental legislation. 3. After the parts mentioned have been removed, the machine is ready to be handed over to an approved scrap merchant. Operator’s Manual – Park Ranger 2150 Leaf Suction Unit...

  • Page 18: Notes

    Notes Operator’s Manual – Park Ranger 2150 Leaf Suction Unit...
  • Page 19 Notes Operator’s Manual – Park Ranger 2150 Leaf Suction Unit...
  • Page 20 Egholm A/S Transportvej 27 DK-7620 Lemvig T. +45 97 81 12 05 F. +45 97 81 12 10 www.egholm.eu info@egholm.dk 90101581-01 EN...
