Summary of Contents for Egholm Park Ranger 2150

  • Page 1 Operator´s manual Snow Plough Park Ranger 2150...
  • Page 2 Dear Customer, Thank you for choosing an Egholm product The Park Ranger 2150 is a Danish designed and manufactured utility machine, which allows you to take a very flexible approach to maintaining outdoor areas. Optimal use of your Park Ranger 2150 Snow Plough To ensure optimal performance from your Park Ranger 2150 snow plough, please read this manual carefully before using the machine.
  • Page 3: Table Of Contents

    5.1 Spare parts – Park Ranger 2150 Snow Plough ....... .
  • Page 4: General Information

    General information...
  • Page 5: Safety

    Do not drive on slopes with an incline of more than 10°. (Picture 3) Max. 10° Do not drive on slopes with an incline of more than 10° Operator’s Manual Park Ranger 2150 Snow Plough...
  • Page 6: Ec Declaration Of Conformity

    · has been manufactured in conformity with the provisions of the Machinery Directive, Directive 2006/42/EU The Park Ranger 2150 fitted with the FH 2100 cab (ROPS approved) · has been tested at the Danish Institute of Agricultural Sciences at Bygholm in conformity with directive 86/298/EEC concerning rear mounted, roll-over protection structures of narrow-track wheeled agricultural and forestry tractors.
  • Page 7: Technical Data

    Snow plough weight 69 kg Clearing width 1,300 mm Ground clearance below scraping edge, lifted 400 mm Ground clearance below support strut 350 mm Spacers per skid Specifications may be changed without prior notice. Operator’s Manual Park Ranger 2150 Snow Plough...
  • Page 8: Operator's Manual

    Operator´s manual...
  • Page 9: Assembly / Disassembly

    Follow the procedure for fitting in reverse order. Put the protective caps on the snap couplings to protect them from dirt. Locking handle on the A-frame - locked AB C Lever A Connector B Operator’s Manual Park Ranger 2150 Snow Plough...
  • Page 10: Before Start-Up

    – such as kerbstones – may damage the snow plough. This damage may cause bolts to snap or parts of the snow plough to bend. Damage of this type is not covered by the warranty. Operator’s Manual Park Ranger 2150 Snow Plough...
  • Page 11: Adjustment

    (Picture 3) 5. Fit the skid and place the remaining spacers on the skid above the scraper guard. 6. Replace the lock ring on the skid. Spacers Remaining spacers Operator’s Manual Park Ranger 2150 Snow Plough...
  • Page 12: Service And Maintenance

    Service and maintenance...
  • Page 13 3. Remove the nuts and bolts holding the scraper edge and remove the scraper edge. (Picture 2) 4. Fit the new scraper edge by reversing the procedure. New scraper edges and skids can be ordered from an authorised Egholm distributor. Operator’s Manual Park Ranger 2150 Snow Plough...
  • Page 14 When the snow plough is to be stored outside the season, we recommend that you remove any loose paint and to repaint any damaged areas. We recommend greasing the attachment or spraying it with protective lubricant. Operator’s Manual Park Ranger 2150 Snow Plough...
  • Page 15: Conditions

    Conditions...
  • Page 16: Warranty

    The warranty period for the materials and manufacture of this snow plough is 12 months from the date of purchase. In case of faults or defects in the machine within the warranty period, Egholm will carry out the necessary repairs without charge for materials and working hours in accordance with the terms and conditions listed below.
  • Page 17: Complaints

    2. Remove the plastic and rubber parts and dispose of them in accordance with the applicable environmental legislation. 3. After the parts mentioned have been removed, the machine is ready to be handed over to an authorised municipal scrap merchant. Operator’s Manual Park Ranger 2150 Snow Plough...
  • Page 18: Wearing Parts

    Wearing parts...
  • Page 19: Spare Parts - Park Ranger 2150 Snow Plough

    Wearing parts 5.1 Spare parts – Park Ranger 2150 Snow Plough 02200060 Tension spring 09724490 Rubber scraping edge 61200898 Skid 90501921 Articulated joint set 01702020 Loose bearings for articulated joint set Operator’s Manual Park Ranger 2150 Snow Plough...
  • Page 20: Notes

    Notes Operator’s Manual Park Ranger 2150 Snow Plough...
  • Page 21 Notes Operator’s Manual Park Ranger 2150 Snow Plough Operator’s Manual Park Ranger 2150 Snow Plough...
  • Page 22 Egholm A/S Transportvej 27 7620 Lemvig, Denmark T.: +45 97 81 12 05 www.egholm.eu - info@egholm.dk...
