Summary of Contents for Egholm Park Ranger 2150
- Page 1 ’ peratOr s manual FLAIL MOWER/ VERTICUTTER Park Ranger 2150 Park Ranger 2150...
-
Page 2: Introduction
Introduction Dear Customer Congratulations with your Egholm product. The Park Ranger 2150 is a Danish designed and manufactured product, which offers a very flexible way of maintaining outdoor areas. Optimal use of your Park Ranger 2150 flail mower/verticutter: To ensure optimal performance of your Park Ranger 2150 flail mower, please read this manual carefully before using the machine. -
Page 3: Table Of Contents
5.1 Wearing parts - Park Ranger 2150 flail mower/verticutter ....... . -
Page 4: General Information
It is recommended that counterweights are fitted to the rear wheels to prevent the machine tipping forwards. Refer to the basic Park Ranger 2150 Operator’s Manual. Avoid hearing damage Use earmuffs when operating the machine. 4 points of lifting Operator’s Manual Park Ranger 2150 flail mower/verticutter... -
Page 5: Ec Declaration Of Conformity
The machine: Flail Mower/Verticutter 2150 21SLK Type: · has been manufactured in conformity with the provisions of the Machinery Directive, Directive 2006/42/EU Place: Lemvig Date: Signature: Knud Olsen, Senior Engineer Operator’s Manual Park Ranger 2150 Flail Mower/verticutter... -
Page 6: Technical Data
Vertical blades: Used for vertical cutting which provides air to the root system of the lawn and removes moss. Counterweights: To be fitted on the rear wheels of the machine Large radiator cover (90203171) recommended for lawn mowing. Operator’s Manual Park Ranger 2150 Flail Mower/verticutter... -
Page 7: Operator's Manual
Removing: Follow the procedure for fitting in the reverse order. Put the protective caps on the snap couplings to protect them from dirt. Locking D-connectors Operator’s Manual Park Ranger 2150 Flail Mower/verticutter... -
Page 8: Before Start-Up
During transport – use the transport lock to fix the flail mower in its raised position. (Picture 1) (Refer to the basic Park Ranger 2150 Operator´s Manual Section 1.5) Check the blades are sharp, intact and free from cracks before fitting the flail mower. This avoids unnecessary Transport lock breakdown while mowing. -
Page 9: Start-Up
Make sure no one puts their fingers or toes under the flail mower while it is moving to avoid personal injury. 7. Stop the flail mower by moving lever D into neutral position. (Picture 3) Operator’s Manual Park Ranger 2150 Flail Mower/verticutter... -
Page 10: Adjustment
(Picture 2) In other words it is an advantage to use as few adjusting rings as possible to achieve the required cutting height. Adjusting rings R-cotter pin Fine adjustment handle Operator’s Manual Park Ranger 2150 Flail Mower/verticutter... - Page 11 3. For vertical cutting, the R-cotter pin must be removed so that the mower is in floating position, as this ensures an even depth and results in an even and thorough treatment of the lawn. (Picture 1) Operator’s Manual Park Ranger 2150 Flail Mower/verticutter...
-
Page 12: Service And Maintenance
1. Remove the oil cooler cover. (Picture 4) 2. Blow the cover and cooler clean with compressed air. Warning! Blow the cooler with compressed air before washing the machine. Otherwise the dirt will not wash off. Oil cooler cover Operator’s Manual Park Ranger 2150 Flail Mower/verticutter... -
Page 13: Maintenance
(Picture 4) Protective screens (avoid stones being thrown out): Check the screens on the front and rear edges of the mower guard for wear, and replace if necessary. Lubricate the castor wheel forks Operator’s Manual Park Ranger 2150 Flail Mower/verticutter... - Page 14 The nut and bolt must not be tightened too much, otherwise the flails will not move. (Picture 3) Bolt for blade The flails are fitted together Operator’s Manual Park Ranger 2150 Flail Mower/verticutter...
- Page 15 When it is time to store the flail mower for the winter, the following steps are recommended: 1. Remove any loose paint and repaint any damaged areas. 2. Spray the flail mower with protective lubricant. Vertical blades fitted individually Operator’s Manual Park Ranger 2150 Flail Mower/verticutter...
-
Page 16: Conditions
The warranty period for the materials and manufacture of this flail mower is 12 months from the date of purchase. In case of errors or defects on the machine within the warranty period, Egholm will carry out the necessary repairs without charge for materials and working hours in accordance with the terms and conditions listed below. -
Page 17: Complaints
2. Remove all plastic and rubber parts and dispose of. 3. After the parts mentioned have been removed, the machine is ready to be handed over to one of your local approved scrap merchants. Operator’s Manual Park Ranger 2150 Flail Mower/verticutter... -
Page 18: Wearing Parts
Wearing parts 5.1 Wearing parts - Park Ranger 2150 flail mower/verticutter E01100300 Wheel E09700290 Stone guard, back edge E90203061 Vertical blade set E09701270 Rubber wheel E01604020 Fan belt E90501681 Flails set E01700040 Bearing for rubber wheel E09701530 Spacer ring E09700280 Stone guard, front edge... -
Page 19: Notes
Notes Operator’s Manual Park Ranger 2150 Flail Mower/verticutter... - Page 20 Egholm A/S Transportvej 27 DK-7620 Lemvig T. +45 97 81 12 05 F. +45 97 81 12 10 www.egholm.eu info@egholm.dk E90101631-01 EN...
