General Notes
Print Principle
Print position
12

3.2 Intermittent Mode

Printhead
Print surface
Figure 3
After starting a print order the printhead moves against the print
medium. Afterwards the printing carriage moves corresponding to the
set or transferred layout length linear over the material which is to be
printed. After the print procedure the printhead again lifts up and the
printing carriage moves again to the starting position.
NOTICE!
The direct print module is delivered with a default print length
of 65 mm. In order to use the maximum print length of 75 mm,
the print position value must be changed to 93.
Figure 4
A: Print pos. / Start pos. value = 93
B: Print pos. / Start pos. value = 83
C: Max. position print end
D: Stand-by position
Service Instructions
Dynacode II
Feed
Packaging material
