BTR140
REV 002A
ELICA DI MANOVRA RETRATTILE
MANUALE D'INSTALLAZIONE E USO
IT
pag. 3
RETRACTABLE THRUSTER
INSTALLATION AND USE MANUAL
EN
page 23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BTR140 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Quick BTR140 Series

  • Page 1 BTR140 REV 002A ELICA DI MANOVRA RETRATTILE MANUALE D'INSTALLAZIONE E USO pag. 3 RETRACTABLE THRUSTER INSTALLATION AND USE MANUAL page 23...
  • Page 3 2 - Fornitura e dotazioni Pag. 5 2.0 - Fornitura di serie e materiale incluso nella confezione Pag. 5 2.1 - Attrezzi necessari per l'installazione Pag. 5 2.2 - Accessori Quick consigliati Pag. 5 ® 3 - Sicurezza Pag. 5 3.0 - Avvertenze...
  • Page 4: Informazioni Sul Prodotto

    è stata progettata e realizzata per effettuare un’apertura del portello priva di interferenze (se installata come indicazioni). Motore elettrico, riduttore, leveraggi e tutti gli altri componenti sono forniti da Quick già assemblati sulla struttura ®...
  • Page 5 • Tronchesi • Trapano con punta da Ø 8,5 mm • Chiave esagonale da 2,5 mm • Chiave a forchetta da 8 mm e 13 mm 2.2 - Accessori Quick consigliati ® per l'azionamento dell'elica di manovra PANNELLI DI COMANDO •...
  • Page 6: Installazione

    4 - Installazione BTR140 4.0 - Posizionamento dell'elica di manovra minimo 0,75 volte il Ø del tunnel • Per evitare fenomeni di cavitazione nell’elica, si dovrà posizionare il tunnel più a fondo possibile. • Per evitare danneggiamenti, posizionare l'elica retrattile in modo che il portello non sia influenzato dal cono di propulsione dell’elica dell'imbarcazione (esempi 1 e 2), in entrambi i sensi di marcia.
  • Page 7 4 - Installazione BTR140 4.1 - Installazione della controflangia Accedere direttamente nella parte interna dello scafo, nella zona in cui l'elica retrattile verrà installata. La posizione dell'elica retrattile dovrà permettere agevoli manovre di installazione. • Proteggere la sede della guarnizione con carta gomma- •...
  • Page 8 4 - Installazione BTR140 Fig. 4 • Realizzare l’apertura dello scafo tagliando lungo la linea dell’area di taglio tracciata (fig. 4). GRP LAYERS Fig. 5 Sistema di laminazione consigliato da Quick ® CONTROFLANGIA GRP LAYERS COLLA STRUTTURALE GRP LAYERS GRP LAYERS SCAFO •...
  • Page 9 4 - Installazione BTR140 4.2 - Realizzazione e installazione del portello di chiusura ATTENZIONE: prestare particolare attenzione ad evitare interferenze tra il coperchio e l’apertura dello scafo. Contatti troppo precisi provocheranno danni all’intero sistema di movimento (fig.7). Fig. 7 Fig. 8 LATO CERNIERA CONTROFLANGIA...
  • Page 10 4 - Installazione BTR140 Fig. 12 ANGOLARE CONTROFLANGIA CERNIERA SCAFO PORTELLO SCAFO 5 mm ATTENZIONE: per permettere un solido fissaggio della cerniera e della staffa, il portello non deve presentare al suo interno zone Fig. 13 N° 2 VITI M8 vuote, o riempimenti non strutturali (fig.
  • Page 11 4 - Installazione BTR140 4.4 - Verifica e regolazione meccanica del sistema Attenersi alla sequenza riportata di seguito per effettuare la verifica dell’apertura fig. 15 del portello: Fig. 15 • L'elica retrattile non deve essere alimentata. • Sfilare l’anello e rimuovere il perno (part. A). •...
  • Page 12 4 - Installazione BTR140 4.6 - Procedura di regolazione ATTENZIONE: la seguente procedura deve essere eseguita da personale qualificato. ATTENZIONE: presenza di parti meccaniche in movimento. Porre particolare attenzione quando si opera sull'elica retrattile se è alimentata. • Assicurarsi che tutti i collegamenti elettrici siano stati compiuti in maniera corretta. fig.
  • Page 13 4 - Installazione BTR140 4.7 - Regolazione attuatore Apertura dello sportello laterale dell’attuatore. fig. 20 Interno dell’attuatore SUPPORTO DI PLASTICA SUPPORTO DI PLASTICA CAM 2 CAM 1 SWITCH FC2 SWITCH FC1 VITE DI FISSAGGIO REGOLAZIONE DI MASSIMA CAMMA REGOLAZIONE DI MASSIMA CHIUSURA DELL'ELICA APERTURA DELL'ELICA •...
  • Page 14: Schema Di Collegamento

    5 - Schema di collegamento BTR140 5.0 - Sistema base BTR140 Esempio di collegamento TCD 1042 TCD 1022 ROSSO NERO ROSSO PROTEZIONE TERMICA NERO STACCABATTERIA INTERRUTTORE MOTORE FUSIBILE VEDI TABELLA A PAG.4 PROLUNGHE (OPZIONALI) SCHEDA FUSIBILE ELETTRONICA RAPIDO 4A RTC R1 BATTERIA 12/24V SDOPPIATORE...
  • Page 15 5 - Schema di collegamento BTR140 5.1 - Scheda RTC R1 PULSANTI MOVIMENTO MANUALE SELETTORE ROTATIVO CORRENTE ATTUATORE DIP-SWITCH SELEZIONE OPZIONI LED VERDE ALIMENTAZIONE COLLEGAMENTO CAN BUS LED BICOLORE STATO ATTUATORE LED ROSSO SEGNALAZIONE PROBLEMI FUSIBILE ATTUATORE NEGATIVO GRUPPO TELEINVERTITORE AL TELERUTTORE SX ROSSO NERO...
  • Page 16: Funzionamento

    6 - Funzionamento BTR140 6.0 - Dip-Switch selezione opzioni SELEZIONE FUNZIONE DIP-SWITCH Riservata (mantenere sempre off) 2 3 4 Indica alla stazione di comando CAN che il propulsore è di prua (OFF) Indica alla stazione di comando CAN che il propulsore è di poppa (ON) Riservata (mantenere sempre off) Riservata (mantenere sempre off) 1 2 3...
  • Page 17 7 - Segnalazioni BTR140 7.0 - Segnalazioni luminose Di seguito si riporta il significato delle segnalazioni luminose fornite dalla scheda RTC R1 (vedi scheda elettronica a pag.13). LED POWER (VERDE) STATO LED DESCRIZIONE SPENTO Scheda non alimentata LAMPEGGIO BREVE Scheda alimentata ma comando non abilitato LAMPEGGIO VELOCE Scheda alimentata e modalità...
  • Page 18: Avvertenze Importanti

    E’ provvisto di protezioni che ne limitano il funzionamento fino ad un tempo massimo, come riportato sul manuale dei comandi. E’ assolutamente vietato bypassare o modificare tali protezioni per aumentare il tempo di funzionamen- to, pena la decadenza della garanzia e di qualsiasi responsabilità da parte di Quick SPA.
  • Page 19: Manutenzione

    Manutenzione BTR140 I Thruster Quick sono costituiti da materiale resistenti all’ambiente marino: è indispensabile, in ogni caso, rimuovere perio- ® dicamente i depositi di sale che si formano sulle superfici esterne per evitare corrosioni e di conseguenza inefficienza del sistema.
  • Page 20 Manutenzione BTR140 BTR 1403012 BTR 1404012 MANUALE D’INSTALLAZIONE E USO BTR140 - REV002A...
  • Page 21 Ricambi BTR140 N° DESCRIZIONE CODICE OSP ROTOR 1500W 12V BTR 140+T FVERFEL1512B14T OSP ROTOR 2200W 12V BTR 140+T FVERFEL2212B14T OSP KIT CASSETTA TELEINV 150A 12V FVSGRCT15012A00 OSP KIT CARTER ‘A’ PER ELICA FVSGCARTABTQA00 OSP KIT ANODI ELICA BTR140 FVSGANBTR140A00 OSP KIT RIDUTTORE BTR140 FVSGGBBT140DA00 OSP KIT ELICA D140 FVSGEL140L00A00...
  • Page 22 Dimensioni elica di manovra retrattile BTR140 564 (20 140 (5 500 (19 MANUALE D’INSTALLAZIONE E USO BTR140 - REV002A...
  • Page 23 Pag. 24 2 - Supplied parts Pag. 25 2.0 - Package contains the following parts Pag. 25 2.1 - Tools needed for installation Pag. 25 2.2 - Quick ”accessories recommended Pag. 25 ® 3 - Safety Pag. 25 3.0 - Warnings Pag.
  • Page 24: Information About The Product

    (if properly installed, as per instructions provided). Electric motor, gear, levers and all other components are supplied by Quick , already assembled on the supporting ®...
  • Page 25: Supplied Parts

    • TFH6 fuseholders TFH3 - TFH6 FUSEHOLDERS 3 - Safety BTR140 3.0 - Warnings • The thruster Quick have been designed and manufactured for nautical use. ® • Do not use these appliances for other uses. • Quick shall accept no responsibility for direct or indirect damages caused by improper use of the appliance or an ®...
  • Page 26: Installation

    4 - Installation BTR140 4.0 - Thruster positioning minimum 0,75 times Ø tunnel • To avoid cavitation in the propeller, the tunnel must be positioned as low as possible. • In order to prevent any damage, position the retractable thruster in such a way that the closing lid is not affected by the propulsion cone of the boat propeller (example 1 and 2), in both directions.
  • Page 27 4 - Installation BTR140 4.1 - Counter flange’s installation Directly access inside the hull, where the thruster will be installed. The thruster position must enable easy maintenance operations. • Pay attention to the installation direction, place the arrow • Protect the gasket with gummed paper tape up to marked on the counter flange towards the bow.
  • Page 28 4 - Installation BTR140 Fig. 4 • Cut the hull along the cutting area previously marked (fig. 4). GRP LAYERS Fig. 5 Laminating system recommended by Quick ® COUNTER FLANGE GRP LAYERS STRUCTURAL ADHESIVE GRP LAYERS GRP LAYERS HULL • Align the counter flange to the hull’s opening and check that the two heights (X) are correct. Resinate the counter flange, or solder it in case of aluminium or steel, according to the techniques the most suitable to the hull’s material (fig.
  • Page 29 4 - Installation BTR140 4.2 - Closing lid’s preparation and installation WARNING: pay particular attention to avoid interferences between the lid and the hull opening. Too precise contacts will cause damages to the entire moving system (fig.7). Fig. 7 Fig. 8 HINGE SIDE COUNTER FLANGE...
  • Page 30 4 - Installation BTR140 Fig. 12 ANGLE BAR COUNTER FLANGE HINGE HULL HULL 5 mm WARNING: in order to allow a stable fixing of hinge and bracket, the lid must present neither empty areas nor non-structural fillings Fig. 13 N 2 SCREWS M8 inside (fig.
  • Page 31 4 - Installation BTR140 4.4 - Mechanical system check and adjustmen Follow the sequence described below to verify the opening of the hatch: fig. 15 Fig. 15 • The BTR propeller should be disconnected from power. • Take the ring off and remove the pin (part. A). •...
  • Page 32: Adjustment Procedure

    4 - Installation BTR140 4.6 - Adjustment procedure WARNING: the following procedure must be carried out by qualified personnel. WARNING: presence of moving mechanical parts. Pay extreme attention when operating on the BTR propeller if con- nected to power. • Ensure that all electrical connections have been properly carried out. fig.
  • Page 33 4 - Installation BTR140 4.7 - Actuator’s adjustment Opening of the actuator’s side lid fig. 20 Actuator’s interior PLASTIC SUPPORT PLASTIC SUPPORT CAM 2 CAM 1 SWITCH FC2 SWITCH FC1 FIXING SCREW ADJUSTMENT OF THE THRUSTER’S ADJUSTMENT OF THE THRUSTER’S MAXIMUM CLOSING MAXIMUM CLOSING •...
  • Page 34: Connection Diagram

    (OPTIONAL) TO THE SERVICES BATTERY FUSE 10A SWITCH QUICK ACTING F TO THE SERVICES BATTERY ACTUATOR COMMON NEGATIVE FOR THE BATTERY GROUPS. WARNING: IN CASE OF OVERTEMPERATURE, THE THERMAL PROTECTION ON THE MOTOR WILL OPEN AND INTERRUPT THE NEGATIVE CONTACT ON THE SOLENOID UNIT. WAIT AS LONG AS THE SYSTEM NEEDS TO REACTIVATE.
  • Page 35 5 - Connection diagram BTR140 5.1 - RTC R1 BOARD MANUAL OPERATION BUTTONS ROTARY SWITCH ACTUATOR CURRENT LIMIT DIP-SWITCH OPTIONS SELECTION GREEN LED POWER CAN BUS LINK BI-COLOUR LED LINEAR ACTUATOR STATUS RED LED ERRORS FUSE ACTUATOR NEGATIVE GROUP REVERSING CONTACTOR TO LEFT CONTACTOR BLACK...
  • Page 36: Operation

    6 - Operation BTR140 6.0 - Option selection Dip-Switch SELECTION FUNCTION DIP-SWITCH Reserved (always keep off) 2 3 4 Informs the CAN control station that the thruster is in the bow (OFF) Informs the CAN control station that the thruster is in the stern (ON) Reserved (always keep off) Reserved (always keep off) 1 2 3...
  • Page 37 7 - Notification BTR140 7.0 - Notification signs Legend of error notifications concerning the RTC R1 board (see the board on page 38) LED POWER (GREEN) LED STATUS DESCRIPTION Board not powered SLOW FLASHING Powered board but disabled control FAST FLASHING Powered board and actuator’s manual movement mode on ON WITH SHORT SWITCHING OFF Powered board but disabled control and active link with the CAN control station...
  • Page 38 It is equipped with protections which limit its operation at a maximum time span, as reported on the controls’ man- ual. It is strongly forbidden to bypass or modify such protections in order to increase the operating time span, lest voiding the warranty and thus lifting any responsibility from Quick SPA.
  • Page 39: Maintenance

    Maintenance BTR140 Quick Thrusters are made in materials that are resistant to the sea environment: In any case, it is indispensable to periodi- ® cally remove salt deposits that form on the outer surfaces to avoid corrosions and consequent system inefficiency.
  • Page 40 Maintenance BTR140 BTR 1403012 BTR 1404012 BTR140 INSTALLATION AND USE MANUAL - REV002A...
  • Page 41: Spare Parts

    Spare parts BTR140 N° DESCRIZIONE CODICE OSP ROTOR 1500W 12V BTR 140+T FVERFEL1512B14T OSP ROTOR 2200W 12V BTR 140+T FVERFEL2212B14T OSP KIT REVERSING CONTACTOR UNIT 150A 12V FVSGRCT15012A00 OSP KIT CARTER ‘A’ FOR PROPELLER FVSGCARTABTQA00 OSP KIT ANODS FOR PROPELLER BTR140 FVSGANBTR140A00 OSP KIT GEARLEG BTR140 FVSGGBBT140DA00...
  • Page 42 Retractable thruster dimensions BTR140 564 (20 140 (5 500 (19 BTR140 INSTALLATION AND USE MANUAL - REV002A...
  • Page 44 MANUALE D'INSTALLAZIONE ED USO INSTALLATION AND USE MANUAL RETRACTABLE THRUSTER Codice di serie del prodotto / Product code and serial number QUICK S.p.A. - Via Piangipane, 120/A - 48124 Piangipane (RAVENNA) - ITALY ® Tel. +39.0544.415061 - Fax +39.0544.415047 - www.quickitaly.com - quick@quickitaly.com...
