PART LIST—Model No. PFIVEX86023.0
Item Description
1 Main frame
2 Front stabilizer
3 Rear stabilizer
4 Handlebar Post
5 Handlebar
6 Seat Post
7 Seat
8 Meter
9 Pedal (L/R)
10 Crank
11 Front End Cap
12 Rear End Cap
13 Carriage bolt
14 Arc washer
15 Acorn nut
16 Arc washer
17 Inner hexagon bolt
18 Cross pan head screw
19 Inner hexagon bolt
20 Lower tension control cable
21 Sensor wire
22 Front Cover
23 Sensor connecting wire
24 Cross pan head screw
25 Arc washer
26 Tension controller
27 Hand pulse wire
28 Flat washer
29 T-shape bolt
30 Handlebar cover
31 Bushing
32 Foam grip
33 Round cap
34 Spring Knob
35 Plastic bushing
36 Knob nut
37 Flat washer
38 End cap
39 Horizontal Seat Post
40 Round cap
41 Cross pan head screw
42 Adjustable device
Qty. Item Description
1 43 Flat washer
1 44 Nylon nut
1 45 Screw
1 46 Chain cover (L/R)
1 47 Turn plate seal
1 48 Turn plate
1 49 Flange nut
1 50 Spring washer
2 51 Bearing
1 52 Hex bolt
2 53 Hex nut
2 54 Sensor
2 55 Screw
2 56 Front cover (L/R)
2 57 Screw
8 58 Belt tray
2 59 Axle
4 60 Flat washer
6 61 Spring washer
1 62 Nylon nut
1 63 Hex nut
1 64 Bolt
1 65 U-Shape washer
1 66 Hex nut
1 67 Nut
1 68 Belt wheel
2 69 Flywheel
1 70 Nylon nut
1 71 Flywheel axle
1 72 Hex bolt
1 73 Spring washer
2 74 Spring
2 75 Magnetic board
1 76 Magnetic
1 77 Magnetic board axle
1 78 Belt
1 79 Idle wheel
2 80 Idle wheel connecting rod
1 81 Nylon nut
1 82 Spring
2 83 Alloy bushing
1 84 Hex bolt
15
Qty.
3
3
22
1
2
2
2
2
2
1
2
1
2
1
4
1
1
6
6
4
2
2
2
2
2
2
1
1
1
2
2
1
1
8
1
1
1
1
1
1
1
1
