8 Is the wireless receiver communicating with the wireless
multiplexer?
Check the LEDs in the upper right-hand corner of the wireless
multiplexer board.
When the wireless receiver is connected and working properly,
LEDs D39 and D41 will blink whenever there is door activity at
the site. See Drawing 20 on page 64
Additionally, when the wireless multiplexer is powered up, the
display on the wireless multiplexer will show
0001
if the wireless receiver is connected.
Yes
– Skip to Step 10
9 Does the display on the wireless multiplexer show any
activity besides
Yes
– Proceed to Step 10
10 Have any transmitters been registered to the wireless
multiplexer?
Yes
– Proceed to Step 11
rev. 7-2017 114A3873.D
Wireless Door Alarm System
No
Receiver On
RECEIVER ON
– Proceed to Step 10
?
No
– Register the
transmitters and retest
No
– Register the
transmitter and retest
