PTI security systems Wireless Door Alarm System Installation And Operation Manual page 48

Drawing 18: Register a range of transmitters
Start
Enter
Starting
Channel
Save Starting
Number
Press
'A REG' on
TRL8080
Press
Reset on
Xmtr
Reset?
YES
NO
YES
Cancel?
NO
Process?
* When no transmitters
were registered:
NO CHANNELS
HAVE BEEN REGISTERED
PRESS # WHEN DONE
43
'A REG' BUTTON ON
TRL8080 BOARD LOCATED
INSIDE RECEIVER
ENTER FIRST CHANNEL
NUMBER TO USE:
PRESS # WHEN DONE
PRESS RESET ON THE
TRANSMITTER FOR
CHANNEL xxxx
PRESS # WHEN DONE
ARE YOU DONE ASSIGN-
Abort
ING TRANSMITTER?
Press # for NO
Y/N YES
NO
Process
Complete
End
CHANNELS xxxx - xxxx
HAVE BEEN REGISTERED
* See Below
* When transmitters
were registered:
PRESS # WHEN DONE
Channel
Used?
Clear Previous
Transmitter
Assignment
Xmtr.
YES
Used?
NO
Assign
Channel &
Set State
Increment to
next Channel
114A3873.D rev. 7-2017
