3 Is the wireless multiplexer display blank?
Yes
Technical Support
4 Is the wireless multiplexer communicating with the
controller?
Check the LEDs on the wireless multiplexer board or run the
system setup report on the controller.
When the wireless multiplexer communicates with the
controller, LEDs D1 – D6 will be blinking. See Drawing 20 on
page 64.
If only D1 and D4 are blinking, proceed to Step 6.
Yes
– Proceed to step
Are any other devices set to the same address as the
5
wireless multiplexer?
Check the addresses on all of the devices, or disconnect the
wireless multiplexer and run the system setup report on the
controller.
If the system setup report shows the remote number (address)
assigned to the wireless multiplexer as being
the multiplexer is disconnected, then another device is sharing
the same address.
Do not use address 22 as it is reserved by the controller.
Yes
– Change one of
the devices and retest
