PTI security systems Wireless Door Alarm System Installation And Operation Manual page 46

Drawing 17: Register a single door transmitter
Start
ENTER CHANNEL NUMBER
Enter
Channel TO REGISTER
PRESS # WHEN DONE
Number
Channel
YES
Used?
NO
Clear
Previous
Assignment
Press
'A REG' on
TRL8080.
PRESS RESET ON THE
Press
TRANSMITTER FOR
Reset on
Xmtr.
PRESS # WHEN DONE
YES
Reset?
NO
YES
Cancel?
NO
Abort
Process?
Y/N
NO
A
41
'A REG' BUTTON ON
TRL8080 BOARD LOCATED
INSIDE RECEIVER
Overwrite
Channel?
Y/N
YES
Go to
A
CHANNEL xxxx
ARE YOU DONE ASSIGN-
ING TRANSMITTER?
Press * for YES
Press # for NO
YES
CHANNEL xxxx HAS NOT
Channel
NOT BEEN REGISTERED!
Saved
Press # to Continue
End
CHANNEL xxxx IS USED
RE-REGISTER IT?
Press * for YES
Press # for NO
NO
Transmitter
Channel
& Set State
Channel
Look Up
by ID
YES
Used?
NO
Clear Old
Assignment
Assign
CHANNEL xxxx
HAS BEEN REGISTERED
Saved
Press # to Continue
End
114A3873.D rev. 7-2017
