Wireless Door Alarm System
Attaching the Transmitter to the Mounting Plate
1 Transmitter boxes have mounting holes, accessible when the
lid is removed. PTI recommends attaching the transmitter
to the mounting plate using these holes as they provides
increased security.
2 Whenever the lid is removed from a transmitter box, the
transmitter sends a tamper alarm. If the transmitter is
attached using the internal mounting holes, the lid cannot be
removed from the base without sounding the tamper alarm.
3 In addition, each transmitter box is equipped with mounting
tabs protruding from each end of the box. Only use these
tabs if the transmitter is mounted in a secure area, such as
inside a locked door.
Note: PTI does not recommend locating transmitters inside
4
locked units where they are not accessible for regular
maintenance.
Remove the cover on the transmitter box.
5
6 Position the transmitter on the mounting plate and attach
it to the plate using the screws provided in the mounting
hardware kit.
7 Check the battery on the transmitter board to make certain
it is seated in the battery holder. Reinstall the cover on the
transmitter box.
Do NOT use adhesive to attach the transmitter the
21
mounting plate
