Wireless Door Alarm System
NOTE: DO NOT allow the PL Premium® adhesive to bleed over
the mounting hole as it could potentially cause damage to the
drill bit when drilling the hole.
When installing the transmitter on the door jamb on a roll up or
similar door, the center of the magnet should align roughly with the
center of the alignment mark on the transmitter box lid. Because
a magnet may need to be raised away from the door jamb, the
transmitter mounting plates are designed to stack. This feature
allows the installer to compensate for the increased gap and
additional mounting plates are available from PTI.

Mounting Door Transmitters

The door type where the transmitter will be installed determines
the correct mounting procedure to use:
NOTE: To ensure an easier installation, PTI recommends that
transmitters are registered with the wireless multiplexer before
attaching them to the mounting plates.
If the system was shipped complete by PTI Security Systems, the
transmitters may have been registered to the multiplexer at the
factory. If so, they will have a number on the transmitter housing
that is the channel number assigned in the multiplexer.
rev. 7-2017 114A3873.D 6
