  • Page 1 System Installation Manual www.ptisecurity.com 800.523.9504 Revised March 2016...
  • Page 2 It is designed to be followed from start to finish for the installation of the Falcon XT Access Control System. If you have any difficulties, we strongly recommend that you review this manual prior to contacting Technical Support.

  • Page 3: Table Of Contents

    International Wire Cross-Reference .................16 Typical Wiring Scheme.....................17 Wire Splicing ......................20 Surge Protection ......................22 Chapter 2: Installation.....................25 Unpacking the Falcon XT ..................26 Installing the Falcon XT ...................27 Controller to Computer Connection ..............28 For USB connections: ..................28 For RS232 connections: ..................28 For Ethernet connections: ..................29 Controller to AI Devices Connection ................30...
  • Page 4 Chapter 3: Troubleshooting ....................41 Troubleshooting Concepts ..................42 Troubleshooting Gates .....................44 Appendix.........................45 System Requirements ....................46 Notices, Disclaimers, and Warnings ................49 Standard 2-year Equipment Warranty ..............51 Equipment Location ....................53 Site Closeout Checklist ....................54 Technical Support.....................58 Technical Support/RMA Request ................59 Returning Equipment ....................60 Site Service History ....................62 Dealer/Servicer Contact Information ................66...

  • Page 5: Chapter 1: Pre-Installation

    1: p hapTEr NSTallaTION Overview Specifications Training Pre-Installation Recommendations Equipment Location and Site Layout Tools Needed Hardware Needed Wire and Cable Needed International Wire Cross-Reference Typical Wiring Scheme Wire Splicing Surge Protection...

  • Page 6: Overview

    Overview The Falcon XT offers the access control industry the most comprehensive hardware and software package. It is revolutionizing the industry by integrating surveillance, access control, intrusion, lighting, custom scripting, and elevator controls all in one package. The Falcon XT provides the following features: •...

  • Page 7: Specifications

    1: p hapTEr NSTallaTION Specifications Power Supply: Input Voltage: 24 VAC – 40 VA or 24 VDC – 2.5 A Current Consumption: 250 mA Maximum Output Voltage: 14 VDC – 2 A Relay Outputs (resistive load): Maximum Switching Voltage: 30 VAC/DC Maximum Switching Current: AC: 10 A (NO) / 3 A (NC) DC: 5 A (NO) / 3 A (NC)

  • Page 8: Pre-Installation Recommendations

    Meeting code is always your responsibility provide at least a 1 year warranty and PTI Security Systems cannot be held liable if you do not on the installation and who is willing to do a paid service install to code.
  • Page 9 It is less expensive and easier to do this up-front than to try and pull wire later. Especially if additional construction is planned. PTI Security Systems can supply the necessary wire for your needs. We recommend that you use this wire as we have tested it over the years and know that, if installed correctly, it works with our system.
  • Page 10 PTI Security Systems immediately (within 5 days of receipt). It is a good idea to plug everything in and verify that you understand the set up prior to the full site installation. Contact...

  • Page 11: Equipment Location And Site Layout

    Use a set of site plans to lay equipment locations and to determine the amount of conduit and wire needed. A copy of this can be sent to your PTI Security Systems Sales Keep a map of the site...

  • Page 12: Door Alarm Multiplexers - Hardwired

    Door Alarm Multiplexers - Hardwired Door alarm multiplexers are generally mounted high on the side of a building or high on a wall in a hallway that allows access by ladder for maintenance if needed, but is out of reach of the general public. Multiplexers should never be mounted inside of a unit that will be rented or otherwise inaccessible.

  • Page 13: Tools Needed

    X. Assorted Tin Snips KK. 9V Battery w/ Test Clips L. 3M E9-Y Crimper Y. Wireless Tester* LL. Conduit Cutter/Reamer M. Crimping Pliers Z. Mux Punchdown Tool* MM. Hack Saw * Note: Items shown with an asterisk are sold by PTI Security Systems.

  • Page 14: Hardware Needed

    M. Cable Clamps and Mounts + Z. Electrical Conduit with Sweep 90 Bends + Note: Assorted lengths, sizes, and types will be needed of these. * Note: Items shown with an asterisk are sold by PTI Security Systems. Mounting Hardware Recommendations Surface Type for Mounting...

  • Page 15: Wire And Cable Needed

    Planning and installing the wiring of a site is a process from PTI Security Systems as we have determined the most ideal that requires a high degree of technical knowledge; we recommend wire over years of experience and that this be done by a trained professional.
  • Page 16 8212 10.15 stranded copper common ground (Direct efficient way to run video signal Burial) on sites with a lot of cameras. Contact a PTI Security Systems 18 AWG, 2-conductor stranded copper Sales Representative for more wwir1802s ** 8760 6.92 wire with overall shield and common information on Baluns.

  • Page 17: International Wire Cross-Reference

    StorLogix Client To Other Workstation(s) with TCP/IP LAN StorLogix Client Cameras Server with StorLogix Server (Includes LogixServer) USB, RS232, or Ethernet line Graphics Falcon XT Controller Computer RS485 Line To Other Access Interface Device(s) Entry Exit Multiplexer Keypad Keypad Welcome Welcome •...
  • Page 18 12VDC POWER CONTROLLER SUPPLY CIRCUIT BOARD DEDICATED POWER SUPPLY FOR SINGLE SIREN ONLY -OR- -OR- REFER TO SIREN MANUFACTURER INSTALLATION INSTRUCTIONS FOR PROPER SIREN WIRING. SOFTWARE COMPUTER EXIT KEYPAD (DC POWER CONNECTION CONNECT TO SHOWN) EARTH GROUND GATE OPERATOR REFER TO GATE OPERATOR MANUFACTURER INSTALLATION INSTRUCTIONS FOR PROPER WIRING TO KEYPAD RELAY.
  • Page 19 1: p hapTEr NSTallaTION TO OTHER AI DEVICES (REFER TO THE 'INSTALLING THE AI DEVICES' CHAPTER FOR SPECS ON AI DEVICES) RELAY BOARD BUILDING ENTRANCE KEYPAD (DC POWER CONNECTION CONNECT TO SHOWN) EARTH GROUND DEDICATED POWER SUPPLY FOR SINGLE 12VDC DOOR STRIKE ONLY POWER 12VDC DOOR...

  • Page 20: Wire Splicing

    For example: If you are following PTI Security Systems’ wiring recommendations, the DC+ wire should be red, 18 AWG stranded copper wire throughout the site.
  • Page 21 1: p hapTEr NSTallaTION 3. Verify that the wires are both seated completely at the bottom of the connector. Then, using a 3M E9-Y crimping tool, crimp down the button on the connector. The crimping tool can be purchased from PTI Splices should be kept to a minimum or Security Systems.

  • Page 22: Surge Protection

    Look • If connecting the Falcon XT using USB, the supplied USB cable must for the words ‘surge protection’ be used as it includes the needed surge protection. Failure to use on the packaging and purchase a this cable for USB connectivity will void your warranty.
  • Page 23 1: p hapTEr NSTallaTION UPS (Uninterruptible Power Supply) - 3 outlets: Back-up battery surge protection. Control Software PC - 3 outlets: Surge protection only. - Power conditioning: There are several types Input power: of power risks to be aware of and protect against: Output power: Brownouts or power sag is when the power at the wall outlet...

  • Page 25: Chapter 2: Installation

    2: I hapTEr NSTallaTION Unpacking the Falcon XT Installing the Falcon XT Controller to AI Device Connection Output Relay Connections Door Input Connections Wiegand Input Connections Power Connections (North America) Power Connections (International) Power Considerations Adding Additional Power Supplies...

  • Page 26: Unpacking The Falcon Xt

    Keys – Used to lock the Falcon XT box after installation and setup are complete to prevent tampering *Images are for reference only and may not exactly represent what is supplied with the Falcon XT controller due to changes in supply or manufacturing.

  • Page 27: Installing The Falcon Xt

    NSTallaTION Installing the Falcon XT The Falcon XT should be installed in a secure, interior area, such as a locking cabinet, room, or closet. Generally, this location should be in close proximity to the StorLogix (control software) computer. The location should have adequate ventilation and air conditioning.

  • Page 28: For Usb Connections

    5. Power-up the router. For USB connections: 1. The USB cable provided with the Falcon XT MUST be used for USB connections as it contains the necessary circuit protection. Failure to use this cable for USB connections will void the warranty on the Falcon XT.

  • Page 29: Controller To Ai Devices Connection

    USB AND SERIAL (RS232) 3) ETHERNET to ETHERNET (328 ft max) PORTS AI devices (Access Interface Devices) are any PTI Security Systems ETHERNET manufactured device that PORT connects to the controller and is used to perform a service in the Controller to AI Devices Connection system.
  • Page 30 4. Repeat this process with the rest of the wires as follows: • Slot 1: Red DC + • Slot 2: Black DC – • Slot 3: White Data + Notes on RS485 • Slot 4: Shield Wire * • Slot 5: Green Data –...

  • Page 31: Output Relay Connections

    2: I hapTEr NSTallaTION Output Relay Connections There are four output relays along the top of the controller circuit board. These four output relays can be used for many things, including controlling gate operators and doors, sirens, alarm shunts, lights, elevator controls, and virtual relays. These functions are programmed in the control software.
  • Page 32 INPUT 4 siren as per manufacturer instructions. PUSH NOTE: RUN CABLES THROUGH HOUSING EXIT KNOCKOUT/CONDUIT BEFORE WIRING TO BOARD. PTI Security Systems relays have a maximum switching capacity of 30V. Devices requiring higher voltage must be wired through contactor blocks.

  • Page 33: Door Input Connections

    2: I hapTEr NSTallaTION Door Input Connections There are eight door input relays on the controller circuit board. Door Inputs 1 – 4 are on the lower left side of the board and Inputs 5 – 8 are on the lower right. These door inputs can be used for door alarm switches, request-to-exit switches, motion sensors, photobeams, pressure pads, and many other types of dry contact switches.

  • Page 34: Wiegand Input Connections

    Wiegand Input Connections There are two Wiegand device inputs on the controller circuit board. These can be connected to most types of Wiegand output devices, such as proximity card readers, key fobs, remote door openers, etc. Refer to the software Help Files for more information on setting up Wiegand inputs.

  • Page 35: Power Connections (North America)

    2: I hapTEr NSTallaTION Power Connections (North America) Power connections can be made during initial setup to ensure that all electrical connections are working correctly, but power should be disconnected until all AI devices are installed and connected and the system is ready for testing.
  • Page 36 Connect the Ground Wire 1. Strip back the green ground wire coiled inside the case, strip back about ½ inch from the end near the warning tag. 2. Use a wire nut to connect the green ground wire to a ground wire running to a copper grounding post or grounded water pipe as per local code.

  • Page 37: Power Connections (International)

    2: I hapTEr NSTallaTION Power Connections (International) Power connections can be made during initial setup to ensure that all electrical connections are working correctly, but power should be disconnected until all AI devices are installed and connected and the system is ready for testing. Never try to install or connect wire while the power is connected to the system.
  • Page 38 Connect the Battery Do not connect the battery until the system is ready to be plugged in and tested, after all AI devices are installed and wired. 1. Slide the black negative battery wire onto the negative pole of the battery. 2.

  • Page 39: Power Considerations

    2: I hapTEr NSTallaTION Power Considerations The controller has a built-in 2 amp power supply. Each AI device that is placed on the line has current draw that must be accounted for in that amperage. Longer lines and more AI devices on the line will also cause the voltage to drop.
  • Page 40 Voltage Considerations Voltage drop is a serious consideration when planning a site. Wire has resistance that reduces the available voltage the further along the line that the voltage travels. Additional AI devices on the line also reduce the voltage. All devices connected to the controller require a minimum of 12VDC to power them.

  • Page 41: Adding Additional Power Supplies

    Altronix RB5 Relay Module that can be recommend that you use PTI Security Systems power purchased from PTI Security Systems. Installation in this manner will supplies to power any PTI AI allow the entire system to be reset from the main controller.

  • Page 43: Chapter 3: Troubleshooting

    3: T hapTEr rOublEShOOTINg Troubleshooting Concepts Troubleshooting Gates...

  • Page 44: Troubleshooting Concepts

    Troubleshooting Concepts Troubleshooting, like detective work, involves taking a number of clues or symptoms and following them back to a logical conclusion. This process can be very difficult if the installer skips steps or assumes answers. The technician must be careful, methodical, and thorough when troubleshooting.
  • Page 45 3: T hapTEr rOublEShOOTINg Ask other pertinent questions, such as: • Was the system working previously? • When did the problem first occur? • When and how did the problem first get noticed? • What was happening immediately before the problem occurred? •...

  • Page 46: Troubleshooting Gates

    Troubleshooting Gates Warning: Installing and troubleshooting gates should only be done by trained service technicians due to the dangers of injury, death, and property damage from electrocution, and the possibility of crushing, breaking, or severing of limbs from moving parts. All gates should be installed and serviced by trained professionals and meet all local, state, federal, and UL guidelines and safety regulations.

  • Page 47: Appendix

    ppENdIx System Requirements Notices, Disclaimers, and Warnings Standard One-Year Equipment Warranty Equipment Location Site Closeout Checklist Contact Information Technical Support Returning Equipment Site Service History Dealer/Servicer Contact Information...
  • Page 48 ppENdIx System Requirements NOTE: If you are using any other software along with ours, it is imperative that you ensure that your computer specifications more than exceed the combined total requirements for all of the software loaded on the computer. StorLogix Computer Requirements These computer requirements are the minimum for running the software by itself.
  • Page 49 Electrical outlet providing 120VAC (United States) or 240VAC (Europe or Australia) We strongly recommend that installation and setup of all computers and any PTI Security Systems equipment be done by a certified, licensed, qualified, and competent technician. PTI Security Systems can recommend local dealers and installers, but it is up to the customer to verify their qualifications and negotiate any pricing or contracts unless we have been specifically contracted in writing to do so for the customer.

  • Page 50: Notices, Disclaimers, And Warnings

    We strongly recommend that installation and setup of PTI Security Systems equipment be done by a certified, licensed, qualified, and competent person. PTI Security Systems can recommend local dealers and installers, but it is up to the customer to verify their qualifications and negotiate any pricing or contracts unless PTI Security Systems has been specifically contracted in writing to do so for the customer.
  • Page 51 PTI Security Systems warrants its Product to the User. The User is responsible for exercising all due prudence and taking necessary precautions for the safety and protection of lives and property wherever PTI Security Systems products are installed. PTI Security Systems does not authorize the use of its products in applications affecting life safety.

  • Page 52: Standard 2-Year Equipment Warranty

    Within the warranty period, PTI Security Systems will repair or replace, at its option, all or any part of the warranted product which fails due to materials and/or workmanship. PTI Security Systems will not be responsible for the dismantling and/or re-installation charges.
  • Page 53 ppendix The following pages contain several forms that may be useful for the site. We recommend that the Equipment Location and Site Closeout Checklist forms be used for most sites. These forms may be copied. List of Forms Equipment Location This form, along with a wiring map of the site, should be kept on-site with this manual.

  • Page 54: Equipment Location

    ppENdIx Equipment Location Site Name:_________________________________ Date of Install:_______________ Site Address:___________________________________________________________ AI Device Type Location on AI Device Purpose of Notes/Other Site Address Device Information * Make additional copies of this form if more space is needed. □...

  • Page 55: Site Closeout Checklist

    Site Name:_________________________________ Date of Install:_______________ Dealer/Installer: _________________________________________________________ Following is a list of the major functions of the installed Falcon XT system. The installer and a representative of the site should review each item and verify functionality. Each item in the categories below should be checked as it is verified in working order. Then the form should be signed at the bottom by the Installer and a representative of the site.
  • Page 56 ppENdIx Site Closeout Checklist (cont’d) Door Alarm System: □ Open and close every alarmed door on-site in sequential order. THIS STEP IS VERY IMPORTANT and can be performed ahead of time and proven by the next step below. □ Print a ‘Site Activity by Date’ for today’s date showing each door opening and closing in sequential order with no mistakes.
  • Page 57 ppendix Site Closeout Checklist (cont’d) Video System: □ Verify that each camera is in focus and can be clearly viewed at monitors. □ Verify that each camera is adjusted to cover the area assigned to it. □ Verify that each camera is sealed properly. □...
  • Page 58 I certify that the installation meets all applicable codes and is installed to PTI Security Systems’ specifications except where code takes precedence. I certify that a representative of the site has been trained in the maintenance and operation of the systems.

  • Page 59: Site Service History

    ppendix Site Service History Complete this form each time installation, service, or maintenance is performed on the system. This history can be very useful in problem-solving if issues arise. Date: Servicing Company: Name & Phone Number of Tech: Services Performed: Date: Servicing Company: Name &...
  • Page 60 ppENdIx Site Service History Date: Servicing Company: Name & Phone Number of Tech: Services Performed: Date: Servicing Company: Name & Phone Number of Tech: Services Performed: Date: Servicing Company: Name & Phone Number of Tech: Services Performed: Date: Servicing Company: Name &...
  • Page 61 ppendix Site Service History Complete this form each time installation, service, or maintenance is performed on the system. This history can be very useful in problem-solving if issues arise. Date: Servicing Company: Name & Phone Number of Tech: Services Performed: Date: Servicing Company: Name &...

  • Page 62: Dealer/Servicer Contact Information

    ppENdIx Dealer/Service Contact Information Please complete the information below and keep this page in the manual so that the customer has this information for future sales, installation, and servicing needs. Dealer who sold the system: Company Name: Contact Person: Address: Phone Number: Fax Number: E-mail:...
  • Page 63 ppendix...
