Center Box - ScrapBox HER HOBBYBOX Assembly Instructions Manual

Center box

= Pin Holes
= Screw Holes
Front of Her HobbyBox
1. Install 6 pins into CB1 (Center Box side panel) as shown
-Install 7 dowels into CB1 as shown
2. Place CB4 (Center Box upper shelf) onto CB1 with pins and dowels inserting into CB4
4 Proprietary, patented product and assembly instructions. Do not copy or distribute.
This side of the
panel is the front
of Her HobbyBox
1
2
CB1
Back of HerHobbyBox
CB1
*Finished edges
should face
CB4
towards the front
of Her HobbyBox.
Check ALL edges
before installing
This side of the
panel is the back
of Her HobbyBox
