oh happy day
YO U' V E RECIEV ED T HE HER HOBBYBOX!
We've done our best to make sure our furniture is easy and fun to build so you can
start crafting as quickly as possible. After assembling your Her HobbyBox, please
email us about your experience at yvonne@theoriginalscrapbox.com.
For a companion video for these instructions, visit this link (link is case sensitive):
http://bit.ly/HHBInstructions
If you have questions regarding your Her HobbyBox, don't hesitate to contact us.
customerservice@theoriginalscrapbox.com
www.theoriginalscrapbox.com
U.S.A./Canada: 801-226-2686 M-F 9am-5pm MST
Germany: +49 40 69632955
Thank you for choosing our products to help you make space to dream and create.
We wish you many happy, organized hours of crafting!
Her HobbyBox Assembly Instructions
U PDAT ED : JA NUA RY 2 019
U PDAT ED : JA NUA RY 2 019
The Original ScrapBox Team

Advertisement

loading
Need help?

Need help?

Do you have a question about the HER HOBBYBOX and is the answer not in the manual?

Questions and answers

Related Manuals for ScrapBox HER HOBBYBOX

Summary of Contents for ScrapBox HER HOBBYBOX

  • Page 1 For a companion video for these instructions, visit this link (link is case sensitive): http://bit.ly/HHBInstructions If you have questions regarding your Her HobbyBox, don’t hesitate to contact us. customerservice@theoriginalscrapbox.com www.theoriginalscrapbox.com U.S.A./Canada: 801-226-2686 M-F 9am-5pm MST Germany: +49 40 69632955 Thank you for choosing our products to help you make space to dream and create.
  • Page 2 You’ll need both a phillips & flathead screwdriver. Always build with the help of a friend. If you need any help with your build, contact our customer service department. They are experts and happy to help you! Proprietary, patented product and assembly instructions. Do not copy or distribute.

  • Page 3: Light Kit

    35 mm (1 1/3 inch) 12mm (1/2 inch) 2 for CB6 Screws for all angle Pins Cams 4 for CB7’s brackets and hinges 4 for CB8’s 2 for CB9 Door and Table Hinges 16 mm (3/5 inch) Screws and Washers for Shelf Pegs Acrylic Guards on Left Door...

  • Page 4: Center Box

    *Finished edges should face towards the front of Her HobbyBox. Check ALL edges before installing Front of Her HobbyBox This side of the panel is the front of Her HobbyBox Back of HerHobbyBox This side of the panel is the back of Her HobbyBox 1.
  • Page 5 12mm (1/2 inch) 3 – Insert 2 cams into holes as shown. With a FLATHEAD SCREWDRIVER turn 180 degrees and lock into place. 3. Insert 2 cams into holes as shown. With a flathead screwdriver, turn cams 180 degrees Attach Angle Bracket with 6 - 12 mm (1/2”) screws with a PHILLIPS SCREWDRIVER .
  • Page 6 1/2 Bolts 5. Install 5 wheels to CB5 (Center Box base) using (20) 1/2” bolts. 5 - Install 5 wheels to CB5 (Center Box base) using 20 1/2” bolts. IMPORTANT: DON’T TIGHTEN, leave *IMPORTANT: do not tighten, leave wheels loose until cams are installed. loose until cams are installed.
  • Page 7 Dowels Screw Pilot Holes 35mm (1 1/3 inch) Dowel Holes 35mm (1 1/3 inch) 12mm (1/2 inch) 7 - Install CB6 (Center Box lower shelf divider) by inserting 2 dowels at the top to be attached to CB3 into dowel 7.
  • Page 8 *Finished edges facing out *Un nished Edge 35mm (1 1/3 inch) 9. Attach first CB7 (Center Box lower shelf divider) with angle bracket holes facing CB1 with 2 dowels for CB4 and (2) 35mm screws for CB3. Do not tighten these screws until all three dividers are in place.
  • Page 9 Angle Brackets Dowels 12mm (1/2 inch) 10. Place CB14 (Base Front Panel) onto dowel on CB1 Install 7 dowels in CB14, CB5, CB3 and CB4 Add 3 angle brackets with 12mm screws to CB8 (1) and CB7 (2) 10 - Place CB14 (Base Front Panel) onto dowel on CB1. Install 7 dowels in CB14, CB5, CB3, and CB4.
  • Page 10 11. Add 6 pins to CB2 (Center Box right side panel). Turn over and carefully fit onto built 11 - Add 6 pins to CB2 (Center Box Right Side Panel). TURN OVER and carefully t onto built section, making section, making sure all pins and dowels are securely in. sure all pins and dowels are securely in.
  • Page 11 CB10 Long Back Panel Center Strip CB11 12. Add: 2 angle brackets attaching CB5 to CB2, 12 - Add: angle brackets attaching CB5 to CB2 1 angle bracket attaching CB14 ot CB2 1 angle bracket attaching CB14 to CB2 – Place CB11 (Upper Back Panel WITHOUT hole) into upper groove of CB1. Add LONG Back Panel Center Strip.
  • Page 12 CB10 Short Back Panel Center Strip CB11 CB13 CB12 18mm (3/4 inch) 13. Add CB13 (lower back panel WITHOUT hole) into groove of CB1 (make sure the screw pilot holes are on the left as shown). Place SHORT Back Panel Center Strip onto CB13 Slide CB12 (lower back panel WITH hole) into groove of CB2 and Center Strip Screw in (6) 18mm screws to Lower Back Panels.
  • Page 13 Angle Brackets **Rotate Center Box onto back as shown** **LOWER CENTER BOX ONTO BACK PANELS AS SHOWN BELOW. 14. Install 4 remaining angle brackets using (36) 12mm screws into areas shown above 14 – Install 4 remaining Angle Brackets using 36 - 12 mm screws into areas shown above. Proprietary, patented product and assembly instructions.
  • Page 14 TABLE 15mm bolts 12mm 18mm (3/4 inch) 15 – Prepare table to be installed onto Center box by: 15. Prepare table to be installed onto Center Box by: 1 – Attach legs with 8 - 15 mm bolts. (DO NOT OVER TIGHTEN) 1.
  • Page 15 12mm WITH A FRIEND 16. Attach table to Center Box by having 1 person hold the table next to hinge pilot holes on CB3. The other person attaches remaining (9) 12mm screws to table hinges into CB3 16 – Attach table to Center Box by having 1 person hold the table next to hinge pilot holes on CB3. The 2 WITH 2 PEOPLE: person then attaches remaining 9 - 12 mm screws to table hinges into CB3.
  • Page 16 Center Box Top Center Box Top 17. Add 4 dowels to CB1 and CB2 (CB8s should already have 4 dowels) 4 pins to Center Box Top. TURN OVER 17 – Add 4 dowels to CB1 and CB2. (CB8 ’s should already have 4 dowels) - Add 4 pins to Center Box Top.
  • Page 17 12 mm Left Box Right Box 18. Attach 4 hinges to Left Waterfall box and 4 hinges to Right Waterfall box using (3) 18 – Attach 4 Hinges to Left Waterfall box and 4 Hinges to Right Waterfall box using 12mm screws per hinge (Make sure barrel is facing out).
  • Page 18 12mm Left Box Right Box WITH A FRIEND WITH 2 PEOPLE: 19 - Attach Left Box to Center Box, and then Right Box to Center Box with 4 Hinges and 12 mm screws 19. Attach Left Box to Center Box and then Right Box to Center Box with 4 hinges using 12mm screws.
  • Page 19 Left Box with Shelves Acrylic guard install *Always use washer to prevent acrylic guard from cracking 12mm 20. Attach Left Box with Shelves to Left Waterfall Box using 12mm screws. 4 hinges should already be attached to the waterfall box. 20 –...
  • Page 20 Right Box with Velcro 12mm 21. Attach Right Box with Velcro to Right Waterfall Box using 12mm screws. Again, 4 21 – Attach Right Box with Velcro to RIGHT waterfall box with 12 mm screws. Again, 4 hinges are already attached to the waterfall box.
  • Page 21 Custom LED light Install Electrical Wire Clips Center Box 22 - To install light into CenterBox crown top, remove 2 rubber plugs and t light strip into crown top opening. 22. To install light into Center Box crown top, remove 2 rubber plugs and fit light strip Make sure cord is on the right as shown.
  • Page 22 Suggested Center Box Shelf Assembly All vertical shelving is adjustable for customizing your craft storage Video Link to help with shelf install: Clear Plastic Totes http://bit.ly/ShelfPegs 6 - 12 1/4 x 12 1/4 x 3 8 - Notions Totes (link is case sensitive) 24 - Notions Dividers 8 - Shoebox Totes 16 - Shoebox dividers...
  • Page 23 Acrylic Guard 16mm (3/5 ninch Screw) Washer Left Box with Shelves Optional: Metal Rods 15 1/4” Rod Attach 7 acrylic guards to Left Box with shelves using 16mm screws and washers. The washers are important to prevent the Acrylic Guards from cracking. Attach 7 acrylic guards to Left Box with Shelves using 16mm (3/5”) screws and washers.
