5. Install 5 wheels to CB5 (Center Box base) using (20) 1/2" bolts.
5 - Install 5 wheels to CB5 (Center Box base) using 20 1/2" bolts. IMPORTANT: DON'T TIGHTEN, leave
*IMPORTANT: do not tighten, leave wheels loose until cams are installed.
loose until cams are installed.
6. Install CB5 (Center Box base) onto pins and dowels. Use 2 cams to lock into place,
turning 180 degrees. Now tighten all bolts on 2 lower and center wheels.
6- Install CB5 (Center Box base) onto pins and dowels. Use 2 cams to lock into place, turning 180 degrees
tighten all bolts on 2 lower and center wheels.
6
Proprietary, patented product and assembly instructions. Do not copy or distribute.
5
1/2 Bolts
6
CB5
CB5
CB4
CB3
CB1
