17. Add
4 dowels to CB1 and CB2 (CB8s should already have 4 dowels)
4 pins to Center Box Top. TURN OVER
17 – Add 4 dowels to CB1 and CB2. (CB8 's should already have 4 dowels)
- Add 4 pins to Center Box Top. TURN OVER.
- Place carefully into dowels on top of Center Box. Make sure pins and dowels are Place carefully into dowels on top of Center Box. Make sure pins and dowels are
secure and Back Panels are snug into Center Box Top groove.
secure and Back Panels are snug into Center Box Top groove.
- Add 4 cams and lock into place.
Add 4 cams and lock into place. Add 4 angle brackets to CB1, CB8(1), CB8(2) and
- Add 4 Angle Brackets to CB1, CB8, CB8, and CB2, connecting to Box Top using 12 mm screws.
CB2, connecting to Box Top using 12mm screws.
16 Proprietary, patented product and assembly instructions. Do not copy or distribute.
Center Box Top
17
Center Box Top
CB8
CB8
CB1
CB2
