18. Attach 4 hinges to Left Waterfall box and 4 hinges to Right Waterfall box using (3)
18 – Attach 4 Hinges to Left Waterfall box and 4 Hinges to Right Waterfall box using
12mm screws per hinge (Make sure barrel is facing out).
3 - 12 mm screws per hinge. (Make sure Barrel is facing out).
