ScrapBox HER HOBBYBOX Assembly Instructions Manual page 23

24
Attach 7 acrylic guards to Left Box with shelves using 16mm screws and washers. The
washers are important to prevent the Acrylic Guards from cracking.
Attach 7 acrylic guards to Left Box with Shelves using 16mm (3/5") screws and washers.
The washers are important to prevent the Acrylic Guards from cracking.
Optional feature: Replace 3 acrylic guards with (3) 15 1/4in. metal rods.
Install rods by placing plastic cups in the pilot holes indicated in the picture above.
Optional feature: Replace 3 acrylic guards with 3- 15 1/4" metal rods.
Install rods by placing plastic cups in the pilot holes indicated in the picture above.
yay you!
CONGRATULATIONS!
NOW YO U'RE READY TO M OV E IN AN D START C REATING. HAPPY C RAF TI NG!
23 Proprietary, patented product and assembly instructions. Do not copy or distribute.
Acrylic Guard
Your
16mm (3/5 ninch Screw)
Washer
Left Box with Shelves
Optional: Metal Rods
15 1/4" Rod
is ready to ll and enjoy!
