ScrapBox SEW STATION Assembly Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
oh happy day
YOU ' V E RECEI V ED T HE SE W STAT IO N !
It's already time for your first project. Let's get to work!
To make things easy, we've broken down the Sew Station assembly instructions
into simple steps. All of the hardware you will need can be found in one bag.
If you have questions at any point of the assembly process, don't hesitate to
reach out to our customer service team. They are the friendliest bunch of
furniture experts and will be happy to help you.
customerservice@theoriginalscrapbox.com
www.theoriginalscrapbox.com
U.S.A./Canada: 801-226-2686 M-F 9am-5pm MST
We are excited for you to enjoy your inspiring new workspace and can't wait to
see pictures! Share your photos on Facebook and Instagram and don't forget
to tag @theoriginalscrapbox. Happy crafting!
UPDATE D: D EC 2 019
The Original ScrapBox Team

Advertisement

loading
Need help?

Need help?

Do you have a question about the SEW STATION and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ScrapBox SEW STATION

Summary of Contents for ScrapBox SEW STATION

  • Page 1 YOU ’ V E RECEI V ED T HE SE W STAT IO N ! It’s already time for your first project. Let’s get to work! To make things easy, we’ve broken down the Sew Station assembly instructions into simple steps. All of the hardware you will need can be found in one bag.
