ScrapBox HER HOBBYBOX Assembly Instructions Manual page 7

35mm (1 1/3 inch)
8
7 - Install CB6 (Center Box lower shelf divider) by inserting 2 dowels at the top to be attached to CB3 into dowel
7. Install CB6 (Center Box lower shelf divider) by inserting 2 dowels at the top to be attached to
holes. Line up CB6 with pilot holes of CB5. Hand screw 2 - 35mm (1/1/3") screws into CB5 to find pilot holes
in CB6. Screw in with PHILLIPS SCREWDRIVE. DO NOT OVER TIGHTEN. BE CAREFUL TO SCREW IN
CB3 into dowel holes. Line up CB6 with pilot holes of CB5. By hand, screw in (2) 35mm screws to
STRAIGHT AS TO NOT SPLIT THE WOOD. TAKE YOUR TIME! Install 2 angle brackets attaching CB1 to
CB5 to find pilot holes in CB6.
CB5.
*Screw in with Phillips screwdriver. Do not over tighten. Be careful to screw in straight so
MUST USE 2 PEOPLE FOR NEXT STEP TO AVOID DAMAGES
as to prevent splitting the wood. Take your time! Install 2 angle brackets attaching CB1 to CB5.
8 - Insert 2 dowels each into the CB8's (Center Box upper dividers). Install lower CB8 first with 2 - 35mm screws,
by hand, then tighten with screwdriver. Make sure the 3 angle bracket holes are facing toward CB1.) TAKE YOUR Be certain to use a friend for the next step to avoid damaging your box!
TIME TO SCREW IN STRAIGHT SO THE WOOD DOES NOT SPLIT.
8. Insert 2 dowels each into the CB8s (Center Box upper dividers). Install lower CB8 first with (2)
- Install upper CB8 (with angle bracket holes facing up) with 2 - 35 mm screws, by hand, then with screwdriver.
35mm screws, by hand, then tighten with a screwdriver. Make sure the 3 angle bracket holes are
Install angle brackets for CB8's.
facing toward CB1. Take your time to screw straight to aviod splitting the wood.
Install upper CB8 (with angle bracket holes facing up) using (2) 35mm screws,
first by hand, then with screwdriver. Install angle brackets for CB8s.
