oh happy day

YO U' VE RECEI VED YOUR SIDE TABL E(S)!

You are minutes away from even more room to create! Installation will be simple

and fun. If you need any assistance, our customer service team is the friendliest

bunch and would be delighted to help you!

customerservice@theoriginalscrapbox.com

www.theoriginalscrapbox.com

801-226-2686 M-F 9am-5pm MST

Remember to take pictures of your craft space. We never get tired of seeing how

you create room for yourself and what you love to do!

Side Table Installation Instructions Made in the U.S.A.

U P DAT E D : J U N E 2 019

The Original ScrapBox Team

Need help?

Do you have a question about the WORKBOX 3.0 Side Table and is the answer not in the manual?

Questions and answers

Summary of Contents for ScrapBox WORKBOX 3.0 Side Table

Page 1 801-226-2686 M-F 9am-5pm MST Remember to take pictures of your craft space. We never get tired of seeing how you create room for yourself and what you love to do! The Original ScrapBox Team Side Table Installation Instructions Made in the U.S.A.
Page 3 more space for everyone Installing your Side Tables in the WorkBox 3.0 Installing your Side Tables in the DreamBox Using the Shelf Peg Tool...
Page 4 WO RK B OX 3 .0 Side Table Installation T O O L S Y O U ’ L L N E E D ( N O T I N C L U D E D ) : Manual phillips Permanent screwdriver marker...
Page 5 Count up 17 shelf peg holes from the bottom and remove all 13 x 13 shelves and shelf pegs from peg hole #17-18 in the left/right box. Also remove notions-sized shelves and shelf pegs that share peg hole #18 in the narrow section(s) of the left/right box. *You may have to rearrange some shelves/totes to make space for the side tables.
Page 6 Hold one track up to the side panel on your left/right box to determine which column of screw holes aligns with the hold pattern on your box. Correct column will vary between boxes. Mark the correct column on both tracks with a permanent marker. outer or inner column outer or inner column Lay both tracks on a hard, ﬂat surface and use a manual...
Page 7 With screw side down, position the table tracks over shelf peg hole #18 on both sides of left and/or right box. Use a manual screwdriver to secure tracks. Proprietary, patented product and instructions. Do not copy or distribute.
Page 8 Install (1) Sash Lock (hook side only) to the underside of the Side Table using the pre-drilled pilot holes closest to the cutaway end. Cutaway end Left Side Table Underside Barrel Lock Catch Pilot Holes Left Side Table Underside 14mm Washer Screws (for table legs) Install (1) Side Table Leg to Side Table using (4) table leg screws into the pre-drilled...
Page 9 Apply Left and/or Right Side Guide Sticker to UNDERSIDE of the WorkBox table in the left/right corner. Be sure sticker is up against the front and outside edges of the table. FRONT underside of WorkBox Table Use the provided screws to attach (1) Sash Lock Catch (per side) with the hook near FRONT...
Page 10 With Side Table Leg folded out, turn the table over. Slide left/right side table(s) into tracks until table touches the back panel of the left/right box. With Center Box table folded out, adjust the legs so your Side Tables are even with the Center Table.
Page 11 who says change isn’t easy? Now you can customize your shelves to accomodate your new side tables, larger bins or cutting machines We’ve included this nifty tool to make installing your shelf pegs and shelves a bit easier. Here’s how to use it: Fit the wide, ﬂat part of the shelf peg into the corresponding hole in the included shelf peg tool.
Page 12 DR E AM BOX SIDE TA BL E IN STAL LATIO N I N ST RU CT IO N S T O O L S Y O U ’ L L N E E D ( N O T I N C L U D E D ) Manual phillips Permanent screwdriver...
Page 13 Count up 18 shelf peg holes from the bottom of the box and remove any 13 x 13 shev- les and shelf pegs from peg hole #18 through #24 in the left/right box. Also remove any notions-sized shelves and shelf pegs in peg holes #19 & 24 in the narrow sec- tion(s) of the left/right box.
Page 14 Hold one track up to the side panel on your left/right box to determine which column of screw holes aligns with the hold pattern on your box. Correct column will vary between boxes. Mark the correct column on all four tracks with a permanent marker. outer or inner column outer or inner column Lay (2) tracks on a hard, ﬂat surface and use a manual Phillips...
Page 15 With screw sides up, position the table tracks over shelf peg hole #18 on both sides of left/right box. Use a manual screwdriver to secure tracks. Proprietary, patented product and instructions. Do not copy or distribute.
Page 16 Lay remaining (2) tracks on a hard, ﬂat surface and use a manual Phillips screwdriver, “start” (4) Euro screws into inner holes of the remaining (2) table tracks. Insert screws just enough to bite the plastic. inner screw holes inner screw holes inner screw holes inner screw holes With screw sides up, position the table tracks...
Page 17 Install (2) Sash Locks (hook side only) to the underside of Side Table using the two sets of pre-drilled pilot holes closest to the end of the Side Table as a guide. Install (1) barrel lock catch in the pilot holes closest to the Barrel Lock Catch cutaway edge.
Page 18 Apply the Left and /or Right Side Guide Sticker to Left/Right Corner of the DreamBox table. Be sure sticker is up against the front outside edge of the table. Use the provided screws to attach (1) Sash Lock Catch (per side) with the hook near the edge of the table using the sticker as a guide.
Page 19 With Side Table Leg folded out, turn the table over. Slide left/right side table into tracks until table touches the back panel of the left/right box. With Center Box table folded down to match the sitting height of the side table, (1) secure the barrel lock at the back of the table, (2) adjust the feet on your Side Table legs so the Side Tables are even with your Center Box table, and (3) lock the sash lock and barrel lock to secure Side Tables to the Center Table.
Page 20 To change side tables to standing height: 1. Release sash lock and barrel lock underneath Side Tables 2. Adjust DreamBox table to standing height 3. Slide side table out of lower tracks 4. With Side Table laying on edge, extend side table legs to the top hole (standing height) 5.
Page 21 who says change isn’t easy? Now you can customize your shelves to accomodate your new side tables, larger bins or cutting machines We’ve included this nifty tool to make installing your shelf pegs and shelves a bit easier. Here’s how to use it: Fit the wide, ﬂat part of the shelf peg into the corresponding hole in the included shelf peg tool.
Page 22 yipee! You’ve done it. Now sit back and enjoy your newly expanded workspace, with three times as much room to dream and create. Remember to share pictures of your crafts and craft space with us on Facebook @ScrapBoxFamily But take care! You must remove your Side Tables before closing our box. Here’s how: 1.
