CEC Version
Operation Manual
Distributed by: Amusements Worldwide
www.amusementsworldwide.com
Tel: 214-750-9202
SERIAL NUMBER:
DATE OF INSTALLATION:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RACE CAR PHOTO RIDE and is the answer not in the manual?

Questions and answers

Related Manuals for UNIS RACE CAR PHOTO RIDE

Summary of Contents for UNIS RACE CAR PHOTO RIDE

  • Page 1 CEC Version Operation Manual Distributed by: Amusements Worldwide www.amusementsworldwide.com Tel: 214-750-9202 SERIAL NUMBER: DATE OF INSTALLATION:...

  • Page 2: Table Of Contents

    RACE CAR PHOTO RIDE Rev.1.11 CONTENT Important Safety Instructions ................. 2 1. SPECIFICATIONS ..................... 4 2. PACKAGE CONTENTS ..................... 5 3. PART NAMES ......................6 4. SET UP & INSTALLATION ..................7 5. HOW TO PLAY ......................11 6. GAME OPTION ....................... 12 7.

  • Page 3: Important Safety Instructions

    RACE CAR PHOTO RIDE Rev.1.11 Thank you for purchasing RACE CAR PHOTO RIDE. We hope you enjoy the product. This manual contains valuable information about how to operate and maintain your game machine properly and safely. It is intended for the owner and/or personnel in charge of product operation.
  • Page 4 RACE CAR PHOTO RIDE Rev.1.11 No Touching Hazard: This part may be hot or can cause electric shock. Do not touch. Use the following safety guidelines to help ensure your own personal safety and to help protect your equipment and surrounding environment from potential damage.

  • Page 5: Specifications

    RACE CAR PHOTO RIDE Rev.1.11 1. SPECIFICATIONS Rated power supply： 110V, 50/60Hz Min. Power consumption： 418W Max. Power consumption： 600W Dimensions： D83.85 x W35.43 x H53.15 (inches) Weight： Approximately 551 (lbs) NOTICE: After turning off the game, please wait at least 1 minute before restarting again.

  • Page 6: Package Contents

    RACE CAR PHOTO RIDE Rev.1.11 2. PACKAGE CONTENTS Open the package and make sure all the items are included: • 1 x Body Assembly • Following accessories Part No. Name Spec. Qty. Illustration Note R106-432-000 Bulb 12V 3W Φ6×30 Choose by...

  • Page 7: Part Names

    RACE CAR PHOTO RIDE Rev.1.11 3. PART NAMES SIDE VIEW Character fiberglass Film box assembly Car fiberglass Electrical box assembly Printer drawer assembly BACK VIEW Camera Coin mechanism LED light Base Fiberglass...

  • Page 8: Set Up & Installation

    RACE CAR PHOTO RIDE Rev.1.11 4. SET UP & INSTALLATION This product is an indoor game machine. Do not install outdoors. Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 3) for places to avoid Place the unit on a dry level surface Ventilation openings in the back of the unit must not be obstructed by objects or by wall.
  • Page 9 RACE CAR PHOTO RIDE Rev.1.11 4.3 Transporting the Game If you need to move the game, adjust the levelers back to an “up” position so the casters touch the ground. Leveler Caster Move   NOTICE • Be careful not to damage the machine during transport.
  • Page 10 RACE CAR PHOTO RIDE Rev.1.11 4.4 Connecting Power WARNING: Check the voltage rating before you connect the equipment to an electrical outlet to ensure that the required voltage and frequency match the available power source. Please refer the label of the machine.
  • Page 11 RACE CAR PHOTO RIDE Rev.1.11 4.5 How to install the printer 3. Pull the hook out from each side and take the back panel out 1. Open the back panel. 2. Pull the hook 5.Take this inner back panel out. And then install the printer to the machine.

  • Page 12: How To Play

    RACE CAR PHOTO RIDE Rev.1.11 4.6 How to take the printer out 2. Open the computer door 2. Remove two screws on both side to take the bracket out. Then take the computer out. 4.7 How to take the computer out Take 4 mounted screws out to remove the computer box.

  • Page 13: Game Option

    RACE CAR PHOTO RIDE Rev.1.11 6. GAME OPTIONS 6.1 Get into the Setting Menu and Button Function Description Open the Electrical side door in order to access to the setting monitor. Press any button to display the content shown on the screen.
  • Page 14 RACE CAR PHOTO RIDE Rev.1.11 6.2.1 Game Mode Free Play: Printer: Demo Music: Save Coins: Volume: Coins Per Round: Each Round Time: Paper format: One Shot Ride with printer error: Back Free Play: OFF- -Play by credits; ON- -Play for free. Default setting: OFF.
  • Page 15 RACE CAR PHOTO RIDE Rev.1.11 6.2.3 Output Test Output Test Front Wheel Light_L 1 Front Wheel Light_L 2 Front Light_L Head Light_L Front Wheel Light_R 1 Front Wheel Light_R 2 Front Light_R Head Light_R Back Wheel Light_L 1 Back Wheel Light_L 2...
  • Page 16 RACE CAR PHOTO RIDE Rev.1.11 6.2.6 Date/Time Setting Year: 2011 Month: Day: Hour (24): 9 Minute: Second: Save & Back Back Set the date and time of the game. Save & Back: The changes will be saved and back to the Main Menu.
  • Page 17 RACE CAR PHOTO RIDE Rev.1.11 6.3 Screen Display & Error Message Explanation Printer operation information is shown on the screen. It is divided into 6 areas from A to F shown as above. A: Display what the camera is viewing during play. It shows “Demo” during Demo Mode.
  • Page 18 RACE CAR PHOTO RIDE Rev.1.11 6.4 Recovery Instruction 1. Turn off the game. Open the computer service door. 2. Insert the USB into the USB interface. 3. Turn on the game. It will get into the system recovery process automatically (below picture will be shown).

  • Page 19: Maintenance, Inspection

    RACE CAR PHOTO RIDE Rev.1.11 7. MAINTENANCE, INSPECTION 7.1 Safety Check Check the points listed before operating the machine. These checks are necessary for safe machine operation: 1. Try to run the game before operation each day. 2. Conduct monthly routine checks of game components ensure good working condition 3.

  • Page 20: Overall Construction

    RACE CAR PHOTO RIDE Rev.1.11 8. OVERALL CONSTRUCTION 8.1 Main Assembly Part No. Name Qty. R-106-001-000 Film mechanism assembly R-106-002-000 Printer drawer assembly R-106-003-000 Computer box assembly R-106-004-000 Fiberglass base assembly R-106-005-000 Fiberglass car assembly...
  • Page 21 RACE CAR PHOTO RIDE Rev.1.11 8.2 Film Mechanism Assembly Part No. Name Qty. Film decal R106-701-000 Film bracket R106-101-000 Camera box R106-102-000 C582 Lock R106-401-000 Film box bracket R106-103-000 Camera R106-402-000 Camera lens R106-403-000 Camera lens plate R106-104-000 Camera lens holder...
  • Page 22 RACE CAR PHOTO RIDE Rev.1.11 8.3 Printer Drawer Assembly Part No. Name Qty. Printer outer box R106-108-000 Printer R106-404-000 Lamp socket R106-405-000 LED light-white R106-406-000 Printer bracket R106-109-000 Slide rail R106-110-000 Paper access R106-111-000 Lock pin R106-112-000 T lock cap...
  • Page 23 RACE CAR PHOTO RIDE Rev.1.11 8.4 Computer Box Assembly Part No. Name Qty. Connecter plate R106-116-000 R106-117-000 Monitor fixed bracket R106-408-000 C582 lock R106-118-000 Electrical bracket R106-119-000 Connecter baffle 2 R106-120-000 PC box cover R106-121-000 Connecter baffle 1 R106-122-000 PC box...
  • Page 24 RACE CAR PHOTO RIDE Rev.1.11 8.5 Fiberglass Base Assembly...
  • Page 25 RACE CAR PHOTO RIDE Rev.1.11 Part No. Name Qty. Fiberglass base R106-601-000 R106-409-000 Speaker R106-125-000 Speaker grill R106-601-000 Protective sleeve R106-126-000 Protective sleeve bracket R106-410-000 Driver R106-127-000 Main base bracket R106-128-000 Power outlet R106-411-000 Gear box R106-129-000 Main motion bracket...
  • Page 26 RACE CAR PHOTO RIDE Rev.1.11 8.6 Fiberglass Car Assembly 17,18 13， 25 11, 12...
  • Page 27 RACE CAR PHOTO RIDE Rev.1.11 Part No. Name Qty. Fiberglass car R106-605-000 R106-606-000 Front light cover - right R106-607-000 Wheel vacuum form R106-608-000 Fiberglass car cover R106-609-000 Fiberglass seat R106-610-000 Fiberglass back seat R106-611-000 Tail light cover R106-419-000 Steering wheel...
  • Page 28 RACE CAR PHOTO RIDE Rev.1.11 8.7 Electrical Parts 10，24 16，...
  • Page 29 RACE CAR PHOTO RIDE Rev.1.11 Part No. Name Qty. Film LED light R106-427-000 Head LED light- yellow R106-428-000 Head LED light- white R106-429-000 Big head LED light- white R106-430-000 LED light socket R106-431-000 LED bulb R106-432-000 Coin counter R106-433-000 Wheel light - big R106-434-000 Wheel light –...
  • Page 30 RACE CAR PHOTO RIDE Rev.1.11 8.8 Decal Parts Part No. Name Qty. Film decal R106-701-000 Camera decal R106-702-000 Camera lens decal R106-703-000 Car triangle LOGO R106-704-000 Car head LOGO R106-705-000 Base top decal R106-726-000 Photo access decal R106-706-000 Base front left side decal...
  • Page 31 RACE CAR PHOTO RIDE Rev.1.11 Part No. Name Qty. Control panel deal R106-710-000 Button decal R106-711-000 Car number decal R106-712-000 Photo frame decal R106-713-000 Wheel vacuum foam R106-714-000 Base front right side decal R106-715-000 Base back side decal R106-716-000...
  • Page 32 RACE CAR PHOTO RIDE Rev.1.11 TY-HM-09 TY-HM-20 TY-HM-20 TY-HM-06 TY-HM-42 TY-HM-19 TY-HM-43 RCAR-HM-18 Part No. Name Qty. R106-717-000 Service sticker R106-718-000 Volume – sticker R106-719-000 Volume + sticker R106-720-000 Reset sticker R106-721-000 Service information sticker 1 R106-722-000 Coin counter sticker...
  • Page 33 RACE CAR PHOTO RIDE Rev.1.11...
