  • Page 1 Operation Manual www.universal-space.com...
  • Page 2 WE ARE HERE TO ASSIST For parts and service Have Questions? Contact us! UNIS SERVICE CENTER Tel: 972-241-4263 Email: service@unispartsandservice.com...

  • Page 3: Table Of Contents

    Extreme Shot GMP Manual CONTENT IMPORTANT SAFETY INSTRUCTIONS ............. 2 1. SPECIFICATIONS .................. 4 2. PACKAGE CONTENTS ................6 3. PART NAME ..................10 4. SET UP & INSTALLATION ..............11 5. HOW TO PLAY ..................25 7. ERROR MESSAGE AND RECOVERY ..........33 8.

  • Page 4: Important Safety Instructions

    Extreme Shot GMP Manual Thank you for purchasing Extreme Shot. We hope you enjoy the product. This manual contains valuable information about how to operate and maintain your game machine properly and safely. It is intended for the owner and/or personnel in charge of product operation.
  • Page 5 Extreme Shot GMP Manual Use the following safety guidelines to help ensure your own personal safety and to help protect your equipment and surrounding environment from potential damage. This product is an indoor game machine. Do not install outdoors. Avoid installing in the following places to prevent fire, electric shock, injury and/or machine malfunctioning: ...

  • Page 6: Specifications

    Extreme Shot GMP Manual 1. SPECIFICATIONS Rated power supply: AC110V50/60Hz; AC220V 50/60Hz Min. Power consumption: 90W Max. Power consumption: 200W Dimension:W40.87×D100.34×H105.12 in Weight：Approximately 573.2 lb Part No: E108 Model No: A-399 NOTICE: After turning off the game, please wait at least 1 minute before restarting again.
  • Page 7 Extreme Shot GMP Manual Dimension for transportation after unpack. 82.56 in 43.50 in 38.39 in Note: Game parameters are subject to change without notice. 07/17/2019...

  • Page 8: Package Contents

    Extreme Shot GMP Manual 2. PACKAGE CONTENTS Open the package and make sure all the items are included: 1. 1 x Body Assembly Name Picture Name Picture Control Main body panel assy. Ball Marquee gate assy. assy. Playfield Beam Front...
  • Page 9 Extreme Shot GMP Manual 2. Following accessories Part No. Code No. Description picture 1 E108-185-000 20113000051 C flat washer 2 E108-186-000 20113000053 C flat washer C large 3 E108-187-000 20113000035 washer Non-metallic 4 E108-188-000 20102040023 hexagon lock Non-metallic 5 E108-189-000 20102040003...
  • Page 10 Extreme Shot GMP Manual Part No. Code No. Description picture Hexagon flat 9 E108-193-000 20101048010 round head screws Cross recessed pan 10 E108-194-000 20101020145 head screw suite Hexagon flat 11 E108-195-000 20101008003 round head screws Hexagon flat 12 E108-196-000 20101100185...
  • Page 11 Extreme Shot GMP Manual Part No. Code No. Description picture 19 E108-443-000 25300171002 20 E108-444-000 25300172002 Photoelectric 21 E108-445-000 21504000001 SW reflector 22 E108-446-000 21901000012 Fuse(220V) 23 E108-447-000 410000017A Basketball 24 E108-448-000 41440000177 Manual Cross recessed 25 E108-200-000 20101010017 countersunk...

  • Page 12: Part Name

    Extreme Shot GMP Manual 3. PART NAME Marquee Assy. Display Gate Assy. Control panel Coin Assy. (card system wiring inside ) Ticket dispenser Assy. 07/17/2019...

  • Page 13: Set Up & Installation

    Extreme Shot GMP Manual 4. SET UP & INSTALLATION NOTICE We do not recommend using power tools as they may cause damage. This product is an indoor game machine. Do not install outdoors.  Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 3) for places to avoid.
  • Page 14 Extreme Shot GMP Manual 4.3 Play Zone This machine requires space for playing and for maintenance as shown below. Leave space around the game upon installation: Service area: 31.5 in Play area: 20 in 30cm Service 操作区 area 本机摆放 Machine...
  • Page 15 Extreme Shot GMP Manual 4.4 How to Install the Machine STEP1 Part E108-278-000 Front bearing Name frame Qty. Part E108-196-000 SPEC. M6X40 Qty. 07/17/2019...
  • Page 16 Extreme Shot GMP Manual STEP2 Part E108-112-000 Cross beam Name Qty. Part E108-111-000 Front middle cross beam Name support bracket Qty. Part E108-196-000 SPEC. M6X40 Qty. 07/17/2019...
  • Page 17 Extreme Shot GMP Manual STEP3 Part E108-012-000 Lock gate door Name assembly Qty. Part E108-193-000 M8X25 SPEC. Qty. BACK VIEW Part E108-188-000 SPEC. Qty. 07/17/2019...
  • Page 18 Extreme Shot GMP Manual STEP4 Part E108-001-000 Front support Name bracket assy. Qty. Part Part E108-191-000 E108-188-000 SPEC. M8X80 SPEC. Qty. Qty. 07/17/2019...
  • Page 19 Extreme Shot GMP Manual STEP5 Part E108-110-000 Back middle cross beam Name support bracket Qty. Part E108-196-000 SPEC. M6X40 Qty. 07/17/2019...
  • Page 20 Extreme Shot GMP Manual STEP6 Part E108-504-000 Front fairway Name board Qty. Part E108-193-000 BACK VIEW M8X25 SPEC. Qty. Part E108-188-000 SPEC. Qty. 07/17/2019...
  • Page 21 Extreme Shot GMP Manual STEP7 Part No. E108-015-000 Control panel Name assembly Qty. Part E108-196-000 SPEC. M6X40 Qty. 07/17/2019...
  • Page 22 Extreme Shot GMP Manual STEP8 Part E108-189-000 SPEC. Part E108-906-000 Qty. L support Part bracket top Name E108-195-000 assembly Qty. SPEC. M6X60 Qty. Part E108-187-000 SPEC. C washer Qty. Part E108-905-000 R support bracket top Name assembly Qty. Part E108-225-000 SPEC.
  • Page 23 Extreme Shot GMP Manual STEP9 Part Part E108-199-000 E108-910-000 Marquee Name assembly SPEC. M6X16 Qty. Qty. STEP10 Part E108-288-000 L side marquee Name assembly Qty. Part E108-289-000 R side marquee Name assembly Qty. Part E108-200-000 SPEC. M4X12 Qty. 07/17/2019...
  • Page 24 Extreme Shot GMP Manual STEP11 Part E108-195-000 SPEC. M6X60 Qty. Part E108-189-000 SPEC. Qty. Part E108-190-000 SPEC. Qty. Part E108-187-000 C washer Qty. Part Part E108-187-000 E108-196-000 SPEC. C washer SPEC. M6X40 Qty. Qty. STEP12 Part E108-188-000 SPEC. Qty. Part E108-192-000 SPEC.
  • Page 25 Extreme Shot GMP Manual STEP13 Part No. E108-440-000 SPEC. Φ10 black Qty. STEP14 Part No. E108-427-000 SPEC. C16×4 Qty. 07/17/2019...
  • Page 26 Extreme Shot GMP Manual 4.6 Wiring Instruction Step 1：Connect the connecters individually according to the labels. Step 2: For reference, this picture is showing the wiring layout of the bottom of the cabinet. (Attach and tighten with nylon cable ties. Part # E108-500-000)

  • Page 27: How To Play

    Extreme Shot GMP Manual 5. HOW TO PLAY 5.1 Insert coins and press button to begin. 5.2 Score instruction Stage 1: Reach 30 points to enter into Stage 2 For single player Stage 2: Reach 60 points to enter into Stage 3...
  • Page 28 Extreme Shot GMP Manual Main board Test: Press TEST button once on the main board, it displays 8.7.6.5.4.3.2.1. and 87654321 to test LED correct or not; Press TEST button once again, it displays1, 1#, 1,2 DIP sw state; Press TEST button once again, it displays 2 for close SW no. 2 positions as 1 SW no.;...
  • Page 29 Extreme Shot GMP Manual 6.1.3 The driver of the Relay and the Ticket dispenser. Open the doors to access the ticket dispenser and relay board. Ticket dispenser Relay board 6.2 Adjustment button instruction Coin meter Ticket Volume Reset the ticket Open the coin door there is a meter panel.
  • Page 30 Extreme Shot GMP Manual 6.2 Setting menu 6.2.1 DIP SW1 Item Content Score per ticket Ticket off 6.2.2 DIP SW1 Item Content Mercy Ticket 6.2.3 DIP SW1 Conte Item Credit & ticket memory 6.2.4 DIP SW2 Item Content Stage per game 6.2.5...
  • Page 31 Extreme Shot GMP Manual 6.2.6 DIP SW2 Item Content High Score Initial Value 6.2.7 DIP SW2 Item Content DEMO music 6.2.8 DIP SW3 Item Content Pass stage score Item Pass stage score Conte Stage Stage Stage Stage Stage 6.2.9 DIP SW3...
  • Page 32 Extreme Shot GMP Manual 6.2.10 DIP SW3 Item Content Rim move Yes- in 3-point time 6.2.11 DIP SW3 Item Content Keep memory Record after Power up Reset 6.2.13 DIP SW4 Item Content Coin per game Error display： If input signal is not in proper status when power on the machine, error code is shown and flashing on the score display.
  • Page 33 Extreme Shot GMP Manual Step 1 Connect the linking cables among the machines. Step 2 Open the front door and find the linking PCB. 07/17/2019...
  • Page 34 Extreme Shot GMP Manual Step 3 Plug the pin cap as picture in the first pin as picture shown to set one machine as host machine. Step 4 Open the front door of another machine and Plug the pin cap in the second pin as picture shown to set another machine as subordinate machine.

  • Page 35: Error Message And Recovery

    Extreme Shot GMP Manual 7. ERROR MESSAGE AND RECOVERY 7.1Trouble Shootings Error code Possible Cause Recommended action Test button broken Change the test button E01Test button The connection part of the test Check and reconnect the loose ports. button is loose.
  • Page 36 Extreme Shot GMP Manual Symptom Possible Cause Recommended action Frame assembly connector fell or Plug in connector tightly. Game will not is loose start Frame assembly fault Contact with UNIS Service. Turn on power SW again. If appeared Circuit protector make power SW...

  • Page 37: Maintenance & Inspection

    Extreme Shot GMP Manual 8. MAINTENANCE & INSPECTION 8.1 Safety Check Check the points listed before operating the machine. These checks are necessary for safe machine operation: 1. Test game before operation each day. 2. Conduct monthly routine checks of game components ensure good working condition 3.

  • Page 38: Overall Construction

    Extreme Shot GMP Manual 9. OVERALL CONSTRUCTION 9.1 Frame Part No. Code Name R side front support bracket E108-008-000 20211603D006 assembly L side front support bracket E108-005-000 20211603D003 assembly E108-501-001 20211603D107B R side front panel E108-264-001 20211603D111A Front R side protect plate...
  • Page 39 Extreme Shot GMP Manual Part No. Code Name E108-504-000 20311603D011 Front fairway board Back middle cross beam support E108-110-000 20211603D034 bracket Front middle cross beam support E108-111-000 20211603D033 bracket E108-112-000 20211603D007 Cross beam 10 E108-277-000 20211603D102 Support beams 11 E108-113-000 20211603D046...
  • Page 40 Extreme Shot GMP Manual 9.3 Moving mechanism 18 19 Part No. Code No. Name E108-125-000 20211603D072A Hoop E108-505-000 20311603D009A Main panel bottom E108-404-000 21501000041 Reflect-sensor E108-269-000 20211603D090A support frame E108-128-000 20211603D096A Hoop B.R. guide rail E108-127-000 20211603D089 Rail shaft E108-136-000 20106000082 Deep groove Ball BR.
  • Page 41 Extreme Shot GMP Manual 9.4 Ball gate mechanism Part No. Code No. Name E108-140-000 20211603D053 Lock gate E108-141-000 20211603D032 Lock gate hinge E108-506-000 20311603D013B Mid track plate E108-142-000 20211603D054A Lock gate fixed plate E108-405-000 23404000235 Motor E108-322-000 20211603D038A Lock gate door motor cover...
  • Page 42 Extreme Shot GMP Manual 9.5 Side light Assy. Part No. Code No. Name E108-148-000 20211603D017 L side light box front cover E108-149-000 20211603D024 R side light box front cover E108-507-000 20311603D003 L side light box board E108-508-000 20311603D004 R side light box board...
  • Page 43 Extreme Shot GMP Manual 9.6 Main panel light Part No. Code No. Name E108-323-000 20611603D006 Main panel L lamp ring E108-324-000 20211603D056 Panel light converted 9.7 Control panel Assy. 07/17/2019...
  • Page 44 Extreme Shot GMP Manual Part No. Code No. Name E108-162-000 20211603D030 Control panel R bottom door E108-163-000 20211603D099 Speaker net E108-164-000 20311603D006 Bass speaker E108-165-000 20211603D035 Coin door E108-294-001 26000042000B New wiring case E108-408-000 22801000055 Ellipse speaker E108-409-000 23100000005 Ticket dispenser...
  • Page 45 Extreme Shot GMP Manual Part No. Code No. Name E108-172-000 20211603D037A Dot matrix cover E108-173-000 20211603D073A Back top support bracket E108-174-000 20211603D069 Hinge R E108-175-000 20211603D068 Hinge L E108-512-000 20311603D010 Main panel top E108-717-000 20511603D028 Main decal E108-608-000 20611603D011 Anti-static plate 1...
  • Page 46 Extreme Shot GMP Manual 9.10 Decal part Part No. Code No. Name 1 E108-701-000 20511603D043 Rear ball track 2 E108-702-000 20511603D042 Mid ball track 3 E108-703-000 20511603D041 Front ball track 4 E108-704-000 20511603D033 L side (Top) decal 5 E108-705-000 20511603D034...
  • Page 47 Extreme Shot GMP Manual Part No. Code No. Name E108-721-000 25600000101 meter label E108-722-000 25600000036 High voltage warning (small) E108-742-000 25600000077 Fuse T10A/250V E108-724-000 25600000071 New voltage 110V E108-725-000 25600000016 Power SW label A E108-726-000 25600000091 New GND label E108-727-000...
  • Page 48 Extreme Shot GMP Manual Part No. Code No. Name E108-744-000 20511603D050 110V label E108-745-000 20511603D051 220V label E108-746-000 20511603D049 Blue decal E108-743-000 20511603D048 step label 07/17/2019...
  • Page 49 Extreme Shot GMP Manual 9.11 Electrical part Coin counter Ticket counter Volume Reset Test Setting 07/17/2019...
  • Page 50 Extreme Shot GMP Manual Part No. Code No. Name 1 E108-414-000 29709030001 V9 board 2 E108-458-000 29711006006 Dot matrix drive PCB E108-449-000 20211603D104A Relay pedestal E108-457-000 22140000002 Solid-state relay 4 E108-417-000 21602000001 Power supply 5 E108-412-000 22801000047 Round speaker 6 E108-419-000 23000000006...
  • Page 51 Extreme Shot GMP Manual Part No. Code No. Name E108-438-002 22002015021 Side light strip 11.7 E108-451-000 22002016035 Marquee light E108-439-002 22002015019 Speaker light E108-408-000 22801000055 Ellipse speaker E108-413-000 22301000001 Coin mech. E108-409-000 23100000005 Ticket dispenser E108-460-000 22008010001 Indicator light E108-461-000 22003000018...

  • Page 52: Wiring Diagram

    Extreme Shot GMP Manual 10. WIRING DIAGRAM 07/17/2019...
