Altronix T2PXK7F8 Trove Paxton kit is pre-assembled and consists of Trove2PX2 enclosure/backplane with factory
installed Altronix power supply/charger and sub-assemblies. T2PXK7F8 kit also accommodates up to eight (8) Paxton Net2
Plus modules for up to eight (8) doors in a single enclosure.
Altronix
Model Number
6.3A/
15A/
T2PXK7F8
250V
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and with all local codes and
authorities having jurisdiction. Product is intended for indoor use only.
1. Remove backplane from enclosure. Do not discard hardware.
2. Mark and predrill holes in the wall to line up with the top three keyholes in the enclosure. Install three upper fasteners
and screws in the wall with the screw heads protruding. Place the enclosure's upper keyholes over the three upper
screws, level and secure. Mark the position of the lower three holes. Remove the enclosure. Drill the lower holes and
install the three fasteners. Place the enclosure's upper keyholes over the three upper screws. Install the three lower
screws and make sure to tighten all screws.
3. Mount included UL Listed tamper switch (Altronix Model TS112 or equivalent)
in desired location, opposite hinge. Slide the tamper switch bracket onto the edge
of the enclosure, approximately 2" from the right side (Fig. 1, pg. 2).
Connect tamper switch wiring to the Access Control Panel input or the
appropriate UL Listed reporting device. To activate alarm signal
open the door of the enclosure.
4. Mount Paxton Net2 Plus modules to TPX2 backplane, refer to page 3.
5. Refer to the eFlow Power Supply/Charger Installation Guide for
eFlow104NB and corresponding Sub-Assembly Installation Guides for the
following models: ACM8, PDS8 and VR6 for further installation instructions.
Hardware:
Nylon Standoff |
- 2 -
Configuration Chart:
Maximum Supply
Current for Main and
Aux. Outputs on
Power Supply board
and ACM8 Access
Power Controller's
outputs
4.5
24VDC @ 9.7A
32V
Installation Instructions:
5/16" Pan Head Screw |
Overview:
Nominal DC
Output Voltage
[DC]
[Aux]
Output
Output
Range
Range
(VDC)
(VDC)
20.17-
20.28-
26.4
26.4
Lock Nut
10A/
2.5A/
8
8
250V
250V
Enclosure
Edge of
Enclosure
Tamper Switch
(provided)
To Access Control Panel or
UL Listed Reporting Device
10A/
3A/
32V
32V
Fig. 1
T2PXK7F8
