- Page 1 Instruction Manual Carmel Corn and Kettle Korn/Chips Stoves Model No. 2080BG and 2080BGK 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA © 2016 Gold Medal Products Co. Part No. 33024...
-
Page 2: Safety Precautions
Carmel Corn and Kettle Korn/Chips Stove Model No. 2080BG and 2080BGK SAFETY PRECAUTIONS DANGER Gas is safe when used properly, but can be very dangerous when used improperly. We suggest that installation be carefully made by qualified personnel only. Gas companies have competent service personnel to provide safe installation. - Page 3 Read and understand operator’s manual and all other safety instructions before using this equipment. To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862 022_060215...
- Page 4 Gold Medal’s Technical Service Department at 1-800-543-0862 for any questions about your machine operations, replacement parts, or any service questions. (Gold Medal Products Co. does not assume any liability for injury due to careless handling and/or reckless operation of this equipment.) gmpopcorn.com...
-
Page 5: Installation Instructions
Carmel Corn and Kettle Korn/Chips Stove Model No. 2080BG and 2080BGK INSTALLATION INSTRUCTIONS Inspection of Shipment After unpacking, check thoroughly for any damage which may have occurred in transit. Claims should be filed immediately with the transportation company. The warranty does not cover damage that occurs in transit, or damage caused by abuse, or consequential damage due to the operation of this machine, since it is beyond our control (reference warranty in back of manual). - Page 6 Carmel Corn and Kettle Korn/Chips Stove Model No. 2080BG and 2080BGK Setup 1. Remove all packaging and tape prior to operation. 2. This unit is for outdoor use only. 3. Place unit in a level position on a surface strong enough to support it when in use. The unit must be placed in a non-combustible location with no trip hazards.
-
Page 7: Gas Requirements
Model No. 2080BG and 2080BGK Gas Installation Instructions Gas Requirements The 2080BG and 2080BGK are designed for Propane only. Converting the unit to an alternate fuel source will void the warranty and may cause a dangerous condition. 2080BG and 2080BGK: Propane Gas, 34,557 BTU/HR NOTE: The unit must be attached to a minimum of 40 pound LPG cylinder. -
Page 8: Checking For Gas Leaks
Stop using the appliance immediately if damage is found, and contact a qualified professional to inspect and correct any issue. 3. Securely route all gas lines away from flames and high temperature areas. 4. Contact Gold Medal Technical Support, or a qualified Gas Service Technician with any questions. Gas Pressure We have determined that optimum cooking occurs when the gas pressure is adequate. - Page 9 Carmel Corn and Kettle Korn/Chips Stove Model No. 2080BG and 2080BGK gmpopcorn.com Page 9...
- Page 10 Carmel Corn and Kettle Korn/Chips Stove Model No. 2080BG and 2080BGK gmpopcorn.com Page 10...
- Page 11 Carmel Corn and Kettle Korn/Chips Stove Model No. 2080BG and 2080BGK gmpopcorn.com Page 11...
- Page 12 Carmel Corn and Kettle Korn/Chips Stove Model No. 2080BG and 2080BGK gmpopcorn.com Page 12...
- Page 13 Carmel Corn and Kettle Korn/Chips Stove Model No. 2080BG and 2080BGK gmpopcorn.com Page 13...
- Page 14 Carmel Corn and Kettle Korn/Chips Stove Model No. 2080BG and 2080BGK OPERATING INSTRUCTIONS Controls and Their Functions GAS SAFETY VALVE The Gas Safety Valve has three settings used to control gas flow; PILOT, ON, and OFF positions. (Reference the Lighting and Shutdown Instructions in the Operating Instruction section of this manual.)
-
Page 15: Lighting And Shutdown Instructions
Carmel Corn and Kettle Korn/Chips Stove Model No. 2080BG and 2080BGK Lighting and Shutdown Instructions Steps to Light the Pilot and Burner: 1. Turn the Gas Safety Valve to the PILOT position. 2. Depress the Safety Valve Button next to the safety valve handle. Hold this button down for 30-45 seconds. -
Page 16: Care And Cleaning
3. Do not leave water in the pans overnight. 4. Wipe unit with soap and hot water. 5. Clean the stainless steel covers with stainless steel cleaner. Gold Medal Products Co.’s Watchdog Stainless Steel Polish (P/N 2088) is recommended. DO NOT use oven cleaners or abrasive materials as they will damage parts of machine. -
Page 17: Maintenance Instructions
Carmel Corn and Kettle Korn/Chips Stove Model No. 2080BG and 2080BGK MAINTENANCE INSTRUCTIONS DANGER Improper installation, adjustment, alteration, service, or maintenance can cause property damage, injury, or death. Any alterations to this equipment will void the warranty and may cause a dangerous condition. This appliance is not intended to be operated by means of an external timer or separate remote-control system. -
Page 18: Ordering Spare Parts
Carmel Corn and Kettle Korn/Chips Stove Model No. 2080BG and 2080BGK ORDERING SPARE PARTS 1. Identify the needed part by checking it against the photos, illustrations, and/or parts list. 2. Use only approved replacement parts when servicing this unit. 3. When ordering, please include part number, part name, and quantity needed. - Page 19 Carmel Corn and Kettle Korn/Chips Stove Model No. 2080BG and 2080BGK Stove Unit - Parts Breakdown 12, 13 14, 15 Aluminum Kettle (Model 2085BGK) gmpopcorn.com Page 19...
- Page 20 Carmel Corn and Kettle Korn/Chips Stove Model No. 2080BG and 2080BGK Stove Unit - Parts List Part Number Item Part Description 2080BG 2080BGK JET BURNER UNIT 32001 32001 BURNER CLIP 105003 105003 BURNER MOUNT 105002 105002 PRESSURE REGULATOR 74115 74115...
