Drill Four
6 mm Holes
1" Scale Block
Keep edge flush
with top of
enclosure
Keep edge flush
with right side
770M/M+/MX PathPilot Operator Console Drill Template
To download/print this template, go to tormach.com/docs
of enclosure
