Problem
The console screen doesn't display an image or respond to the power button.
Cause
The console isn't receiving power.
Solutions
You Might
Probability
Need To...
Examine power High
input to the
console.
Test the power Low
button
functionality.
©Tormach® 2020
Specifications subject to change without notice.
How-To Steps
Examine the green LED on the power brick
for the console. If it's not lit, examine the
power cords to the power brick.
Examine the green ring around the power
button. It should light up when you press
the power button.
Page 10
Need More?
If your console receives power from the Accessory Input ports
on the machine, look for tripped breakers inside your
machine's electrical cabinet.
