STM32W-EXT
The extension kit package contains two STM32W108 application boards (MB851) and two
STM32W108 application boards with a power amplifier (MB954).
Figure 2.
MB851 application board
Note:
1
For documentation concerning the STM32-Primer2 tool, refer to the related user manual on
the
http://www.stm32circle.com
2
For information concerning the STM32W108xx application boards, refer to the
documentation with each available software and documentation tree installer file (see
Section 1.7: Software libraries and demonstration
1.2
MB850 hardware description
1.2.1
MB850 resources
None
1.2.2
MB850 connectors
The following table lists the connectors available in the MB850 board and their functions.
Table 2.
Header 6H
Header 10X2
www.BDTIC.com/ST
website.
ors
MB850 connect
Type
Doc ID 16999 Rev 5
Figure 3.
MB954 application board with a
power amplifier
applications).
Label
JP1
JP2
Getting started
Function
SWD debug
Connector to Primer2 board
7/37
